Korg SV-1 StageVintage - Korg SV-1 Parts Catalog; Electronic Components

SV1 PART LIST
D1-73 = Disassembly 1 (73keys) D1-88 = Disassembly 1 (88keys) D2 = Disassembly 2 D3-73 = Disassembly 3 (73keys) D3-88 = Disassembly 3 (88keys)
D4 = Disassembly 4 D5-73 = Disassembly 5 (73keys) D5-88 = Disassembly 5 (88keys) CP1 = Control Panel group 1
CP2 = Control Panel group 2 CP3 = Control Panel group 3 CP4 = Control Panel group 4
PLS = PLastic Side groups KB = KeyBoard group OB = Output Board group POS = POwer Supply group TB = TuBe group KBB = KeyBoard Base group
PART LIST ELECTRONIC COMPONENTS
CODE DESCRIPTION REFERENCE Q. 88k Q. 73k
GRA0002143 MAIN BOARD D4 1 1
GRA0002144 IN/OUT BOARD OB 1 1
GRA0002145 LEFT PANEL BOARD CP2 1 1
GRA0002146 RIGHT PANEL BOARD CP2 1 1
GRA0002153 VALVE AUDIO BOARD TB 1 1
GRA0002154 VALVE SOCKET BOARD TB 1 1
GRA0002155 HEADPHONE BOARD PLS 1 1
GRA0002161 KEYBOARD INTERFACE KB 1 1
GRA0002162 MAIN LINE FILTER D5-73 D5-88 1 1
TRA0004003 POWER SWITCHING SUPPLY PT45C POS 1 1
PART LIST MAIN BOARD GRA0002143
CODE DESCRIPTION Q.TY
CIN0002040 IC NJM4580M OP. AMP. SMD 3
CIN0002075 DSP TG01 MB87M4080PB-G 1
CIN0010072 USB DEVICE TRANCEIVER ISP1105W 1
CIN0002077 INT. SYST.PROC. MC9328MX1VM20 1
CIN0003043 SDRAM256Mb MT48LC16M16A2P-75:D 1
CIN0003047 IC NOR FLASH AT49BV163AT-70TU 1
CIN0004005 RESET GEN. 3.3V WITH INPUT 1
CIN0010000 CONV.D/A 24BIT CS4398-CZ H100 1
CIN0010029 NANDFLASH K9F2G08U0M-PCB0 1
CIN0010031 IC BUFFER, SN74LVC541APWR 2
CIN0010033 QUAD 2IN OR GATE SN74LVC32APWR 1
CIN0010034 HEX SCHM.TRIG.INV.SN74LV14APWR 1
CIN0010035 HEX.UNB. INV. SN74AHCU04PW 1
CIN0010037 SDRAM 64MB 16B K4S641632K-UC75 1
CIN0010038 QUAD2IN AND GATE SN74ALVC08PWR 1
CIN0010047 1.2A ADJ DCDC CONV.TPS62040DGQ 1
CIN0010054 STEREO CODEC CS4271 1
CIN0010056 ONE GATE NOR SN74LVC1G02DCK 1
CINL010005 P2ROM MR26T51203L-10DTM03A 1
CINL010006 P2ROM MR26T51203L-10ETM03A 1
CINL010007 P2ROM MR26T51203L-10FTM03A 1
CINL010008 P2ROM MR26T51203L-10GTM03A 1
CON0001075 BLACK CON. PICOFLEX 12V P1.27 1
CON0001076 BLACK CON. PICOFLEX 16V P1.27 1
CON0010001 CON. M. V. PTH 2F.10V.1.27MM 1
CON0010016 VER.M.CON. PTH 1F 3V 2.5MM JST 1
CON0010035 VER.M.CON.PTH 1F 7V 2,5MM JST 1
CON0010091 BLACK CON.PICOFLEX 14V P1,27 1
QUA0006004 SMD QUARTZ HCM49 16MHz 1
QUA0006005 SMD QUARTZ HCM49 24.576MHz 1
QUA0006012 SMDQUARTZ PKG CM200S 32.768KHZ 1
TRS0002008 REG. 78L05(SOT89) 100MA SMD 1
TRS0010011 REG.LIN.SMD 2A ADJ LOW DROP 1
FUS0010000 POLYSW 0,75A 6V NANOSMDC075F 1
FEL0010070 GRA0002143 KTP TEST LABEL 1
