SV1 PART LIST
D1-73 = Disassembly 1 (73keys) D1-88 = Disassembly 1 (88keys) D2 = Disassembly 2 D3-73 = Disassembly 3 (73keys) D3-88 = Disassembly 3 (88keys)
D4 = Disassembly 4 D5-73 = Disassembly 5 (73keys) D5-88 = Disassembly 5 (88keys) CP1 = Control Panel group 1
CP2 = Control Panel group 2 CP3 = Control Panel group 3 CP4 = Control Panel group 4
PLS = PLastic Side groups KB = KeyBoard group OB = Output Board group POS = POwer Supply group TB = TuBe group KBB = KeyBoard Base group
PART LIST HARNESSES
CODE DESCRIPTION REFERENCE Q. 88k Q. 73k
CAV0010023 HARNESS KEYBOARD SV1-88 KB 1
CAV0010047 HARNESS MAIN LINE SV1 CP1 1 1
CAV0010048 HARNESS PT45C - I/O BOARD SV1 OB 1 1
CAV0010049 HARNESS MB SUPPLY SV1 OB 1 1
CAV0010050 HARNESS HEAD PHONE SV1 PLS 1 1
CAV0010051 HARNESS TUBE SOCKET SV1 TB 1 1
CAV0010052 HARNESS VOLUME SV1 OB 1 1
CAV0010053 HARNESS USB SV1 OB 1 1
CAV0010054 HARNESS FRONT PANEL EARTH POS 1 1
CAV0010055 HARNESS I/O - TUBE REACTOR SV1 TB 1 1
CAV0010056 HARNESS MB - RIGHT PAN. SV1 CP2 1 1
CAV0010057 HARNESS LEFT - RIGHT PAN. SV1 CP2 1 1
CAV0010058 HARNESS MB - DIGITAL I/O SV1 OB 1 1
CAV0010059 HARNESS MB - ANALOG I/O SV1 OB 1 1
CAV0010060 HARNESS MB - KEY_INT. SV1 73 D4 1
CAV0010065 HARNESS KEYBOARD SV1 73 KB 1
CAV0010066 HARNESS MB - KEY_INT. SV1 88 D4 1
CAV0010067 HARNESS GROUND 140MM PLS 2 2
RIL0001040 EURO MAIN CABLE 1 1
PART LIST OTHER COMPONENTS
CODE DESCRIPTION REFERENCE Q. 88k Q. 73k
LEG0010055 SV1-88 KEYBOARD W BASE KB 1
LEG0010056 SV1-73 KEYBOARD W BASE KB 1
MAN0010024 MULTILINGUAL USER MANUAL SV1 1 1
MAN0010032 USER INSTRUCTION FOR MUSIC STOPPER 1 1
MSD0001007 SV1 CD DRIVER, OS & RES. MAN 1 1
KEYBOARD 88K
TAS0010000
order only every single component directly from KORG Inc. (Japan)
KB 1
KEYBOARD 73K
TAS0010006
order this code and every single component directly from KORG Inc. (Japan)
KB 1
TAS0010008 PEDALE DAMPER DS2H 1 1
PART LIST KEYBOARD WOODEN BASE LEG0010055 (88keys)
CODE DESCRIPTION Q.TY
FEL0010072 CALIFORNIA 93120 COMPLIANT LABEL 1
LEG0010055 SV1-88 KEYBOARD W BASE 1
VTA0001039 SCREW 2.9X9.5TC SLFTHREA.ZN SP 6
VTA0010056 STAND BUSH 2
PART LIST KEYBOARD WOODEN BASE LEG0010056 (73keys)
CODE DESCRIPTION Q.TY
FEL0010072 CALIFORNIA 93120 COMPLIANT LABEL 1
LEG0010056 SV1-73 KEYBOARD W BASE 1
VTA0001039 SCREW 2.9X9.5TC SLFTHREA.ZN SP 6
VTA0010056 STAND BUSH 2
