Korg TRITON proX Service Manual

TRITON proX Parts List Ver1.00
Parts code Parts name and Spesfication PCB No. Unit Price(Yen)
475002806 HARNESS HNS-2806 M.PART 80
475002807 HARNESS HNS-2807 M.PART 810
475002809 HARNESS HNS-2809 M.PART 80
475002810 HARNESS HNS-2810 M.PART 560
475008054 HARNESS HNS-8054 M.PART 10
480010380 DIN JACK YKF51-5041 (3P) KLM-2084 110
500024000 X-410 SPONGE SPACER KOC-F40666 M.PART 10
500027900 X-313 FRONT BAR SPACER F40740 M.PART 10
525001300 FERRITE CORE NFT-25 M.PART 80
540007200 WIRE BAND PLT-1M M.PART 10
540008600 SPIRAL CLIP CS-8 M.PART 10
540008601 SPIRAL CLIP CS-6 M.PART 10
540013100 CLIP A-1T M.PART 20
540020200 INLET SOCKET SS-7B M.PART 30
540021900 PLASTIC SUPPORT PS-610 M.PART 10
540023800 PLASTIC SUPPORT PS-312 M.PART 10
540023900 CIRCUIT BOARD SPACER MSPLS-6 M.PART 10
550016800 X-313 KEYBOARD FELT KOC-F40734 M.PART 50
575016700 LED SPACER LH-3-2 KLM-1827 10
575018400 LED SPACER LH-5-4.5 L=4.5MM KLM-2086 10
600005100 AC CORD KP-610 GTBS-3 KS-31AY M.PART UK 830
600005300 AC CORD DC-480-J01 M.PART JP 210
600005400 AC CORD EC-652-E03 M.PART WG 280
600005400 AC CORD EC-652-E03 M.PART GE 280
600005400 AC CORD EC-652-E03 M.PART FR 280
600005700 AC CORD UC-953-J01 M.PART US 210
600005700 AC CORD UC-953-J01 M.PART CN 210
600005800 AC CORD SC-111-J01 M.PART AU 250
620024600 X-952 POWER SW KNOB E40304-2 M.PART 20
620034400 X-610 2-LINKAGE B-2-GR M.PART 40
620034500 X-610 2-LINKAGE A-2-GR M.PART 40
620034600 X-631 SVR KNOB E40239-6 M.PART 10
620034700 X-610 ENCODER KNOB E40466-2 M.PART 30
620034800 X610 CONTROL KNOB ASSY M.PART 60
620034900 X610 2-LINKAGE KNOB A-1-GR M.PART 20
620035000 X610 2-LINKAGE KNOB B-1-GR M.PART 20
620035100 4-LINKAGE KNOB B-1-LG E20180 M.PART 10
620035200 4-LINKAGE KNOB A-1-LG E20180 M.PART 10
620035300 4-LINKAGE KNOB A-2-LG M.PART 20
620035900 KNOB P422-9PF(D.GR/W) M.PART 10
630029200 X-620 SHIELD SHEET L F40838-1 M.PART 50
630029300 X-620 SHIELD SHEET R F40838-2 M.PART 50
641026204 X-122 HINGE 2 KOC-C40872 M.PART 70
641031300 X-120 STOPPER PLATE KOC-C40887 M.PART 10
641031900 GND SPRING (A) KOC-C40890 M.PART 20
641032100 X-122 FRONT BAR SPACER 2 M.PART 50
641039700 X-115 POWER SW METAL FITTING M.PART 70
641041270 X-311/S/312 GND SPRING (H) M.PART 20
641041277 X-513/4/5 JACK PLATE 4 C41053 KLM-2084 40
641041320 X-313 FDD ANGLE L KOC-C30488 M.PART 80
641041321 X-313 FDD ANGLE R KOC-C30489 M.PART 60
641041326 X-313 FRS ANGLE KOC-C41058 M.PART 40
641041411 X-616 JOINT ANGLE 1 M.PART 60
641041436 GND PLATE M1866-A KOC-C40884-2 M.PART 10
641041479 X-013 JACK PLATE 5 KOC0C41132 M.PART 40
641041528 X-7100/7110 PCB BOX KOC-C10209 M.PART 390
641041530 X-7100/7110 OP PLATE C41143 M.PART 20
