TRITON proX Parts List Ver1.00
Parts code Parts name and Spesfication PCB No. Unit Price(Yen)
641041534 X-7100/7110 LCD ANGLE C41145 M.PART 20
641041538 X-8100 PANEL KOC-C10206 M.PART 5,070
641041545 X-8100 FRONT BAR KOC-C10184-3 M.PART 910
641041548 X-8100 OP COVER A KOC-C41150 M.PART 190
641041549 X-8100 OP COVER B KOC-C41151 M.PART 140
644006200 X-011/012 WHEEL SPRING C40848 M.PART 10
644007700 GND SPRING KOC-C46014 M.PART 10
645052811 X-8100 BOTTOM CASE KOC-D10080 M.PART 2,070
645052812 X-8100 SIDE PLATE L D30152-2 M.PART 1,100
645052813 X-8100 SIDE PLATE R D30152-1 M.PART 1,100
646038900 X-011/012 JOYSTICK FRAME M.PART 40
646039000 X-011/012 VR PLATE KOC-E40309 M.PART 20
646039100 X-011/012 WHEEL SUPPORT E40308 M.PART 20
646039200 X-011/012 JOYSTICK LEVER M.PART 30
646070500 X-7100/7110 LCD HOOD E10167 M.PART 130
646071100 X-610 ENCODER FRAME E40467-2 M.PART 40
646071200 X-511/2 JS COVER E20134-4 M.PART 40
646071300 X-511/2 JS WHEEL E30148-4 M.PART 30
646071400 SVR FRAME ASSY 30LG M.PART 40
646071600 X-313 KEY BLOCK KOC-E20171-2 M.PART 130
646071700 X-313 JS PANEL KOC-E10119-2 M.PART 230
