Korg TRITON Service Manual

TRITON proX Parts List Ver1.00
Parts code Parts name and Spesfication PCB No. Unit Price(Yen)
2072160 72PIN SIMM 16MB M.PART 4,610
2202090 POWER SUPPLY UNIT KLM-2090 M.PART 2,260
304000050 TR 2SA1175 T ALL KLM-2085 10
304000050 TR 2SA1175 T ALL KLM-2084 10
304020070 TR 2SC2785 T ALL KLM-2085 10
304020150 TR 2SC1623-T1B (L7) KLM-2083 10
304020180 TR 2SC2878 A/B TPE2 KLM-2084 10
304020370 TR 2SC2655-Y KLM-2091 10
304050140 DIGITAL TR DTC114EKA T146 KLM-2089 10
304050150 DIGITAL TR DTA114EKA T146 KLM-2089 10
304050220 DIGITAL DTC114ESA TP KLM-2085 10
312010900 LED GL3ED8 KLM-2086 20
312013600 LED MOB31CR KLM-1827 10
313005000 TOUCH PANEL LCD KGJ-01S-5 M.PART 7,800
314001300 DIODE 1SS-133 T-77 KLM-2084 10
314001300 DIODE 1SS-133 T-77 KLM-1827 10
314001400 DIODE RLS-73 TE-11 KLM-1828 10
314003300 DIODE ERA83-004-V1 KLM-2091 20
314010300 DIODE 1S2076TD KLM-2085 10
314010300 DIODE 1S2076TD KLM-2086 10
314010310 LED HLMF-K200#2UM KLM-2085 10
314010310 LED HLMF-K200#2UM KLM-2086 10
314028200 ZENER DIODE RD5.1MW-T1B KLM-1828 10
314028800 LED SLZ-190B-09-T2 KLM-2086 10
314028800 LED SLZ-190B-09-T2 KLM-2085 10
314030100 ZENNER DIODE RD9.1ES T4 AB2 KLM-2084 10
315000500 DOUBLE DIODE MC-2840-T12-1 KLM-2083 10
315000800 DOUBLE DIODE MC-982-T12 KLM-2084 10
320001233 IC UPD71051GB-3B4 (44P QFP) KLM-2083 240
320001242 IC UPC4570HA KLM-2084 30
320004191 IC HD74HC125P KLM-2085 30
320004359 IC HD74HC05P KLM-2084 20
320004538 IC HD63266F KLM-2083 560
320004659 IC HD6433394A31F KLM-2089 560
320004663 IC HD64F7045F28 KLM-2083 2,770
320011026 IC M5216L KLM-2084 30
320011139 IC M5M34050P KLM-2084 210
320011184 IC M66271FP KLM-2083 690
320012223 IC MB87F1710 KLM-2083 2,080
320013131 IC IR3M03A KLM-2091 50
320040038 IC MX23C6410MC-10 BK4-H KLM-2083 710
320040039 IC MX23C6410MC-10 BK4-L KLM-2083 710
320040040 IC MX23C6410MC-10 BK5-H KLM-2083 710
320040041 IC MX23C6410MC-10 BK5-L KLM-2083 710
320040051 IC MX29F1610MC10C5 7100A KLM-2083 970
320040052 IC MX29F1610MC10C5 7100B KLM-2083 970
324001015 IC UPC4570G2-E2 (SOP) KLM-2083 30
324003004 IC TC7S08F(TE85L) KLM-2083 20
324003010 IC TC7WU04F TE12L KLM-2083 20
324003043 IC TC7W74F(TE12L) KLM-2083 30
324004003 IC HD74HC139FPER KLM-2083 20
324004004 IC HD74HC32FPEL KLM-2083 20
324004006 IC HD74HC00FPEL KLM-2083 20
324004024 IC HD74HC74FPER KLM-2083 20
324004050 IC HD74HC138FPEL KLM-2089 20
324004065 IC HD74HC164FPEL KLM-2083 40
324004146 IC HD74HC595FPER KLM-2083 60
1/5

Korg TRITON Specifications

General

Type	Workstation
Oscillators	2 per voice
MIDI	In/Out/Thru
Effects	2 master effects, 1 insert effect
Keyboard	61 keys
Sequencer	16 tracks, 200, 000 notes
Waveform Memory	16MB
Floppy Disk Drive	3.5 inch 2DD/2HD
Optional	EXB-PCM expansion boards
Storage	Floppy disk
Audio Outputs	L/Mono, R, Individual 1-4
Polyphony	62 voices
