Korg TRITON Service Manual

TRITON proX Parts List Ver1.00
Parts code Parts name and Spesfication PCB No. Unit Price(Yen)
324004168 IC HD74HC4053FPEL KLM-2089 30
324009004 IC NJM78L05UA-TE2 KLM-2083 20
324011012 IC M51953BFP-600C (SOP) KLM-2083 20
324011017 IC M5218AFP-600C KLM-1828 20
324011017 IC M5218AFP-600C KLM-2083 20
324013018 IC PQ3TZ53U KLM-2083 80
324021005 IC AT93066-10SI/SC-2.7 KLM-2083 70
324021014 IC SN74LV138ANS-EL KLM-2083 30
324021015 IC SN74LV08ANS-EL KLM-2083 10
324021016 IC SN74LV32ANS-EL KLM-2083 10
324036008 IC PCM1716E/2K KLM-2083 260
324036009 IC PCM1800E/2K KLM-2083 330
324039001 IC KM416C1200BJ-6 KLM-2083 550
324039003 IC KM48C2104CK-6T/L6T KLM-2083 550
330001400 PHOTO COUPLER PC-910K KLM-2084 100
334000500 SB COIL SBT-0260 TF KLM-2084 20
335005600 CRYSTAL OSC. AT-49 16.0MHZ KLM-2089 70
335005600 CRYSTAL OSC. AT-49 16.0MHZ KLM-2083 70
335006500 CRYSTAL OSC. AT-49 24.576MHZ KLM-2083 70
335010700 CRYSTAL OSC. HC-49US 7.00MHZ KLM-2083 40
350002210 SEMI FIXED VR RH0615C13J8WA KLM-1828 10
350002410 SEMI FIXED VR RH0615C15 100K KLM-1828 10
360024500 VR RK11K1140ADWA 10KB(SPECIAL) KLM-1511/12 50
362007500 VR RK09K1110BJFA-10KB KLM-2084 30
362009007 VR RK11K1140AJ08 KLM-2085 50
362009007 VR RK11K1140AJ08 KLM-2086 50
362009015 VR RK09K12ACO KLM-2084 70
365007800 SLIDE VR RS30111AC00NB 10KB KLM-2085 50
365009500 SLIDE VR EWA NA0C10B14 10KB KLM-2085 50
370005000 REC EC11B15204A5 KLM-2086 140
373009000 SLIDE SW SSSS928400 KLM-2084 40
373009300 SLIDE SW ESD-11V121 KLM-2083 30
374000600 TOUCH SW EVQ11A09K KLM-2085 10
374000600 TOUCH SW EVQ11A09K KLM-2086 10
375010900 TOUCH SW EVQPAC07K KLM-1827 10
375012500 POWER SW SDDF3-1A-2 M.PART 110
400015700 POWER TRANSFORMER T-130-1 KLM-2091 330
402002800 COIL 2943-666671 KLM-1935 30
402400200 COIL SBCP-8015H KLM-2091 60
404000500 CHIP SOLID INDUCTOR BLM21B102SPT TS KLM-2089 10
404000500 CHIP SOLID INDUCTOR BLM21B102SPT TS KLM-2083 10
415003200 BUZZER CB-12AP-03 KLM-2091 40
415003700 KX-7100 SENSOR 1 M.PART 560
420005500 KEYBOARD AEII-88 KG2 M.PART 24,960
430008459 F.D TNFD-00P/01P M.PART 210
435002200 FDD DF354H912C M.PART 2,200
450003100 PHONE JACK LGR4609-7000 KLM-1935 20
450003100 PHONE JACK LGR4609-7000 KLM-2084 20
454005600 PHONE JACK YKB21-5006 KLM-2084 50
464400100 FUSE 125V 1A 251001 T-26 KLM-2091 60
471071501 CONNECTOR TOP B15B-PH-K-S(U) KLM-2089 10
471101040 CONNECTOR TOP SC25-04WS KLM-2091 10
471101050 CONNECTOR TOP SC25-05WS KLM-2083 10
471101050 CONNECTOR TOP SC25-05WS KLM-2084 10
471102030 CONNECTOR TOP SJ20-03WX KLM-2084 10
471102030 CONNECTOR TOP SJ20-03WX KLM-2091 10
471102030 CONNECTOR TOP SJ20-03WX KLM-1935 10
2/5

Korg TRITON Specifications

General

Type	Workstation
Oscillators	2 per voice
MIDI	In/Out/Thru
Effects	2 master effects, 1 insert effect
Keyboard	61 keys
Sequencer	16 tracks, 200, 000 notes
Waveform Memory	16MB
Floppy Disk Drive	3.5 inch 2DD/2HD
Optional	EXB-PCM expansion boards
Storage	Floppy disk
Audio Outputs	L/Mono, R, Individual 1-4
Polyphony	62 voices
