Korg TRITON Service Manual

TRITON proX Parts List Ver1.00
Parts code Parts name and Spesfication PCB No. Unit Price(Yen)
471102050 CONNECTOR TOP SJ20-05WX KLM-2083 10
471102050 CONNECTOR TOP SJ20-05WX KLM-2084 10
471102060 CONNECTOR TOP SJ20-06WX KLM-2085 10
471102060 CONNECTOR TOP SJ20-06WX KLM-2083 10
471102060 CONNECTOR TOP SJ20-06WX KLM-2089 10
471102060 CONNECTOR TOP SJ20-06WX KLM-2084 10
471102070 CONNECTOR TOP SJ20-07WX KLM-2089 10
471102070 CONNECTOR TOP SJ20-07WX KLM-2083 10
471102080 CONNECTOR TOP SJ20-08WX KLM-2083 10
471102090 CONNECTOR TOP SJ20-09WX KLM-2083 10
471102100 CONNECTOR TOP SJ20-10WX KLM-2089 10
471102110 CONNECTOR TOP SJ20-11WX KLM-2089 10
471102110 CONNECTOR TOP SJ20-11WX KLM-2086 10
471102110 CONNECTOR TOP SJ20-11WX KLM-2085 10
471102120 CONNECTOR TOP SJ20-12WX KLM-2083 10
471102120 CONNECTOR TOP SJ20-12WX KLM-2085 10
471102120 CONNECTOR TOP SJ20-12WX KLM-2089 10
471102120 CONNECTOR TOP SJ20-12WX KLM-2091 10
471102140 CONNECTOR TOP SJ20-14WX KLM-2083 10
471102140 CONNECTOR TOP SJ20-14WX KLM-2084 10
471102140 CONNECTOR TOP SJ20-14WX KLM-2089 10
471102150 CONNECTOR TOP SJ20-15WX KLM-2085 10
471102150 CONNECTOR TOP SJ20-15WX KLM-2089 10
471102160 CONNECTOR TOP SJ20-16WX KLM-2089 10
471102160 CONNECTOR TOP SJ20-16WX KLM-2086 10
472092060 CONNECTOR SIDE SJ20-06WM KLM-1828 10
472092090 CONNECTOR SIDE SJ20-09WM KLM-1828 10
472093150 CONNECTOR SIDE SB20-15WL KLM-1827 10
474020600 CONNECTOR 52080-0510 KLM-1828 30
474021000 CONNECTOR 34P 5332-34T2 KLM-2083 60
474021200 CONNECTOR 40P 5332-40GS1 KLM-2083 90
474021300 DIN CONNECTOR TC7927-28-401 KLM-2084 60
474028600 CONNECTOR IL-G-4P-S3T2-SA KLM-2091 20
474028700 CONNECTOR 08FDZ-ST-BHL KLM-2085 50
474028800 CONNECTOR 008370-141-000-800 KLM-2091 40
474028900 SIMM CONNECTOR 52706-7220 KLM-2083 160
475002197 HARNESS HNS-2197 (BOARD IN) KLM-1827 40
475002198 HARNESS HNS-2198 (BOARD IN) KLM-1511/12 40
475002761 HARNESS HNS-2761 M.PART 40
475002764 HARNESS HNS-2764 M.PART 20
475002767 HARNESS HNS-2767 M.PART 50
475002771 HARNESS HNS-2771 M.PART 110
475002772 HARNESS HNS-2772 M.PART 70
475002791 HARNESS HNS-2791 M.PART 40
475002792 HARNESS HNS-2792 M.PART 50
475002793 HARNESS HNS-2793 M.PART 40
475002794 HARNESS HNS-2794 M.PART 40
475002795 HARNESS HNS-2795 M.PART 80
475002796 HARNESS HNS-2796 M.PART 80
475002797 HARNESS HNS-2797 M.PART 80
475002798 HARNESS HNS-2798 M.PART 30
475002799 HARNESS HNS-2799 M.PART 70
475002800 HARNESS HNS-2800 M.PART 60
475002801 HARNESS HNS-2801 M.PART 40
475002803 HARNESS HNS-2803 M.PART 90
475002804 HARNESS HNS-2804 M.PART 60
475002805 HARNESS HNS-2805 M.PART 110
3/5

Korg TRITON Specifications

General

Type	Workstation
Oscillators	2 per voice
MIDI	In/Out/Thru
Effects	2 master effects, 1 insert effect
Keyboard	61 keys
Sequencer	16 tracks, 200, 000 notes
Waveform Memory	16MB
Floppy Disk Drive	3.5 inch 2DD/2HD
Optional	EXB-PCM expansion boards
Storage	Floppy disk
Audio Outputs	L/Mono, R, Individual 1-4
Polyphony	62 voices
