CAUTION
LOW BATTERY WARNING INSTRUCTION
※If the problem still occur, please contact your KOSO dealer.
The following situation do not necessarily indicate a malfunction. Please check the following points before taking it in for repair.
The LED indicator doesn’t light up.
●Improper connection between the connectors.
→Check each connectors to make sure the connections are OK .
●The fuse is burned.
→Replace the 4A fuse.
●If the volatage goes bellow 11,5V for more than 5 seconds, the heated grips will turn OFF automoatically.
●The LED indicator will turn Purple and flash to indicate low voltage.
●Press the button once during warning to temporarely deactivate the warning.
Testing environment under 25 Degrees Celsius. Working voltage at 13.5V.
To restore the normal operating status: make suree the voltage is above 12.5V.
●Do not push the rubber part too
hard, otherwise the heated grip
might break.
●Do not bend the in-line control
unit, otherwise it might break.
6
5
wh111am01b
4
TROUBLE SHOOTING
7
Level 1 Temperature Curve
Level 2 Temperature Curve
Level 3 Temperature Curve
Level 4 Temperature Curve
Level 5 Temperature Curve
0 5
10
20
30
40
50
60
70
80
0
10 15 20 25 30
(Minute)
(℃)
TROUBLE-1
CHECK POINT
APOLLO HEATED GRIPS DATA
NOTE
NOTE
