29
PL,DE,GB,RU-045AB/f.453
Technical data
KDE
9 12 15 18 21 24 27
PPE2, KDE2, PPVE
9/12/15 18/21/24 27
Rated power kW 9 12 15 18 21 24 27
Rated voltage 400V 3~
Rated current A 3 x 13,0 3 x 17,3 3 x 21,7 3 x 26,0 3 x 30,3 3 x 34,6 3 x 39,0
Efciency (at Δt = 40°C and water pressure at 0,4 Mpa)
l/min 3,3 4,3 5,4 6,5 7,6 8,7 9,8
Min. connecting wires section
KDE
mm
2
4 x 1,5 4 x 2,5 4 x 4 4 x 6
(PPE2, KDE2, PPVE) 4 x 2,5 4 x 6
Max. connecting wires section mm
2
4 x 16
The maximum allowed network impedance Ω 0,43 0,37 0,30
Pressure in the water mains MPa 0,1 ÷ 0,6
Activation point (min. rate of ow) l/min 2,5
Temperature adjustment range °C 30 ÷ 60
Overall dimension (height
without tap set x width x depth
KDE, KDE2
mm
440 x 245 x 120
PPE2, PPVE
440 x 245 x 126
Weight
KDE
kg
~5,2
KDE2 ~4,3
PPE2, PPVE ~4,0
Water ttings G 1/2” (distance between inlet and outlet 100 mm)
The minimal resistivity of water at 15
0
C for PPE2, KDE2 , PPVE is 1100 Ω cm.
