Kospel KDE2 Assembly And Operating Manual

Technical data
The minimal resistivity of water at 15
0
C for PPE2, KDE2 , PPVE is 1100 Ω cm.
KDE.4 9 12 9 12
Rated power kW 9 12 9 12
Rated voltage 240V~ 230V~
Rated current A 37,5 50 39,1 52,2
Efciency (at Δt = 40°C and water pressure at 0,4 MPa) l/min 3,3 4,3 3,3 4,3
Min. connecting wires section mm
2
3 x 10 3 x 6 3 x 10
Max. connecting wires section mm
2
3 x 25 3 x 16
PPE2, PPVE, KDE2 9/11/12/15 17/18/21/24 27
Rated power kW 9 11 12 15 17 18 21 24 27
Rated voltage 400V 3~
Rated current A 3x13,0 3x15,9 3x17,3 3x21,7 3x24,7 3x26,0 3x30,3 3x34,6 3x39,0
Rated voltage 380V 3~
Rated current A 3x13,7 3x16,7 3x18,2 3x22,8 3x25,8 3x27,3 3x31,9 3x 36,5 3x41,0
Efciency (at Δt = 40°C and water
pressure at 0,4 MPa)
l/min 4,3 5,2 5,8 7,2 8,1 8,7 10,1 11,6 13
Min. connecting wires section mm
2
4 x 2,5 4 x 6
Max. connecting wires section mm
2
4 x 16
The maximum allowed network
impedance
Ω 0,43 0,37 0,30
Overall dimension (height without
tap set x width x depth
mm 440 x 245 x 126
Weight kg ~4,0
KDE 9 12 15 18 21 24 27
Rated power kW 9 12 15 18 21 24 27
Rated voltage 400V 3~
Rated current A 3x13,0 3x17,3 3x21,7 3x26,0 3x30,3 3x34,6 3x39,0
Rated voltage 380V 3~
Rated current A 3x13,7 3x18,2 3x22,8 3x27,3 3x31,9 3x 36,5 3x41,0
Efciency (at Δt = 40°C and water
pressure at 0,4 MPa)
l/min 4,3 5,8 7,2 8,7 10,1 11,6 13,0
Min. connecting wires section mm
2
4x1,5 4x2,5 4x4 4x6
Max. connecting wires section mm
2
4x16
The maximum allowed
network impedance
Ω 0,43 0,37 0,30
Overall dimension (height with-
out tap set x width x depth
mm 440 x 245 x 120
Weight kg ~5,2
Pressure in the water mains MPa 0,1 ÷ 0,6
Activation point (min. rate of ow) l/min 2,5
Temperature
adjustment range
NORMAL mode
°C
30 ÷ 60
SHOWER mode 30 ÷ 55
Water ttings G 1/2” (distance between inlet and outlet 100 mm)
