Kramer TP-574

Technical Specifications
11
6 Technical Specifications
Table 4 includes the technical specifications
1
.
Table 4: Technical Specifications of the TP-573 and TP-574
TP-573 TP-574
INPUTS: 1 HDMI connector, 1 bidirectional IR
port on a 3.5mm mini jack, 1
bidirectional RS-232 port on a 9-pin
D-sub connector
1 CAT 5 IN on an RJ-45 connector
OUTPUTS: 1 CAT 5 OUT on an RJ-45 connector 1 HDMI connector, 1 bidirectional IR
port on a 3.5mm mini jack, 1
bidirectional RS-232 port on a 9-pin
D-sub connector
BANDWIDTH: Supports up to 1.65Gbps bandwidth per graphic channel
COMPLIANCE WITH
HDMI STANDARD:
Supports HDMI and HDCP
RS-232 BAUD RATE: Up to 38400kbps
POWER SOURCE: 12V DC, 510mA 12V DC from TP-573
DIMENSIONS: 12.1cm x 7.18cm x 2.42cm (4.76" x 2.83" x 0.95"), W, D, H
WEIGHT: 0.3kg (0.67lbs) approx.
ACCESSORIES: 12V DC power supply
OPTIONS: RK-3T 19” rack mount, Kramer remote external receiver
2
, Kramer BC-DGKat524 (CAT
5 24AWG), BC-DGKat623 (CAT 6 23AWG) and BC-DGKat7a23 (CAT 7a 23 AWG)
cables
1 Specifications are subject to change without notice
2 C-A35M/IRR or C-A35M/IRE or C-A35M/2IRE
