Connecting a VM-4H 1:4 HDMI Distributor
8
6 Connecting a VM-4H 1:4 HDMI Distributor
To connect the VM-4H as a 1:4 HDMI distributor, do the following:
1. Connect an HDMI source (for example, a DVD player) to the INPUT
connector.
2. Connect the four OUTPUT connectors
1
to up to four HDMI acceptors, as
follows:
 OUTPUT 1 connector to HDMI acceptor 1 (for example, an
LCD TV)
 OUTPUT 2 connector to HDMI acceptor 2 (for example, a
plasma display)
 OUTPUT 3 connector to HDMI acceptor 3 (for example, a
plasma display)
 OUTPUT 4 connector to HDMI acceptor 4 (for example, a
plasma display)
3. Connect the power cord to the mains electricity.
4. Turn ON the POWER.
5. Acquire EDID (see section 7
).
1 As required. Up to 4 outputs can be connected on the VM-4H. Not all outputs need to be connected
