KRAMER: SIMPLE CREATIVE TECHNOLOGY
Acquiring the EDID
10
7.2 The Normal Operation State
In the Normal operation state, you can toggle between the following
working modes:
• Sending the EDID from a selected output to the input (see section
7.2.1
)
• Sending the default EDID to the input (see section 7.2.2
)
• Sending the auto
1
EDID to the input (see section 7.2.3)
To enter the Normal Operation State,
turn the machine ON while pressing the SELECT button.
LEDS 1 and 2 flash three times
7.2.1 Acquiring the EDID from a Selected Output
To select an EDID from a selected output, do the following:
1. Press the SELECT button, as required, to reach the desired output, which
flashes.
2. Press the READ button.
The EDID of the selected output is stored in the non-volatile memory when
the READ button no longer illuminates as well as the selected output LED.
7.2.2 Restoring the Default EDID
To restore the default EDID, do the following:
1. Press the SELECT button several times until the OUTPUT LEDs flash
simultaneously.
2. Press the READ button.
The READ button illuminates.
The default EDID is stored in the non-volatile memory when the READ
button no longer illuminates as well as the output LEDs.
7.2.3 Acquiring the Auto EDID
To acquire the Auto EDID, do the following:
1. Press the SELECT button several times until the OUTPUT LEDs flash in
sequence.
2. Press the READ button.
The READ button illuminates.
1 The auto EDID is an adjusted calculation of the EDIDs of all the connected outputs
