Technical Specifications
11
The auto EDID is stored in the non-volatile memory when the READ
button no longer illuminates as well as the output LEDs.
8 Technical Specifications
Table 2 includes the technical specifications:
Table 2: Technical Specifications
1
of the VM-4H 1:4 HDMI Distributor
INPUT: HDMI connector
OUTPUTS: 4 HDMI connectors
BANDWIDTH: Supports up to 2.25Gbps bandwidth per graphic channel
COMPLIANCE WITH HDMI
STANDARD:
Supports HDMI and HDCP
CONTROLS: SELECT and READ buttons for selecting and storing EDID information
INDICATOR LEDs: OUTPUTS 1 to 4, and ACTIVE LED
POWER SOURCE: 100-264V AC, 50/60Hz, 16VA
DIMENSIONS: 19" x 7" x 1U W, D, H rack mountable
WEIGHT: 2.5kg (5.5lbs) approx.
ACCESSORIES: Power cord, rack “ears”
OPTIONS: HDMI/HDMI male-to-male cables
1 Specifications are subject to change without notice
