Kramer VP-419XL User Manual

6
VP-419xl - Overview
#
Feature
Function
8
INPUT
SELECTOR
CV Button
Press to select the composite video source
9
YC Button
Press to select the s-Video (YC) video source
10
COMP. Button
Press to select the component video source
11
SXGA Button
Press to select the SXGA source
12
INPUTS
YC 4-pin Connector
Connects to the s-Video source
13
CV RCA Connector
Connects to the composite video source
14
Y RCA Connector
Connects to the interlaced component video source
Not compatible with progressive scan Y, Pb, Pr or HDTV
For component video, connect all three connectors: Y, Cb,
Cr (also known as YUV)
15
CB RCA Connector
16
CR RCA Connector
17
SXGA PASS 15-pin
HD Connector
Connects to the VGA/Y, Pb, Pr source
This PC input signal is not scaled, but is available for pass-
through when the PC source is selected
18
SXGA / HD OUT 15-pin HD
Connector
Connects to the SXGA or HDTV (component video)
acceptor
19
12 VDC
+12V DC connector for powering the unit
