Operating press. continuously adj. 10 - 130 bar (1900 PSI) (1 - 13 MPa)
Nozzle size 25045
Permissible overpressure 150 bar (15 MPa)
Water output at 2,800 r.p.m. 10 l/min
Water inlet temperature max. 60 °C
Hose drum no
Steel-weave high-pressure hose 10 m
Detergent suction yes
Total stop system no
Connected load 230 V~, 12.0 A, 50 Hz
Power input P 1 - 2.8 kW
Power output P 2 - 2.0kW
Weight 22 kg
Dim. incl. pulling handle in mm 300 x 330 x 800
Sound level acc. to DIN 45 635 88 dB (A)
Sound level with Dirtkiller 90 dB (A)
Acoustic power L
WA
93 dB (A)
Recoil at lance approx. 27 N
Vibration at lance 1.9 m/s
2
Order no. 41.240
Kränzle 1132
Technical data
4
Permissible tolerance for figures ± 5 % acc. to VDMA uniform sheet 24411
