31
K 1050 TS T
Pos. Bezeichnung Stück Art.-Nr.
1 Gehäuseplatte 1 49.200
2 Öldichtung 12 x 20 x 5 3 43.081
3 O-Ring 78 x 2 1 49.201
4 Plungerfeder 3 49.203
5 Federdruckscheibe Ø12mm 3 49.219
6 Plunger 12 mm AC mit Wellensicherungsring 3 49.209
7 Wellensicherungsring Ø12mm 3 49.230
8 Taumelscheibe 10,0° 1 49.202-10,0
9 Öleinfüllschraube 1 43.437
10 Axial-Rillenkugellager 3-teilig 1 49.208
13 Schraube M 6 x 30 4 43.037
14 O-Ring 14 x 2 1 43.445
Oil change
If oil needs to be changed during repair, the unit is to turned into horizontal
position with its head upside down prior to unscrewing the drain plug over a
container. The oil is to be captured in a container and subsequently properly
disposed of. Then screw oil plug back on again over a container. Use small
funnel when refilling with fresh oil.
Fresh oil: 0.1 l - Kränzle Gear Oil (40.092 2) or W 15/40.
