Dear customer
We would like to congratulate you on your new high pressure cleaner with integrated
undercarriage and integrated hose drum and to thank you for the purchase.
To ease your introduction to the use of the cleaner, we have provided the following
pages of explanations, tips and hints, which we ask you to read before using for the
first time.
The equipment will assist you professionally in all cleaning tasks, e.g.:
Permissible tolerance for figures ± 5 % in acc. with VDMA uniform sheet 24411
Technical
specifications
Operating pressure,
steplessly adjustable
Perm. overpressure
Water output
Hot water input
Suction height
Inj. for cleansing agents
High pressure hose
Electrical ratings
Connect. wattage input
output
Weight
Dimension with mounted
handle in mm
Sound level acc.to
45635
with dirtkiller
Recoil at lance
Torque
Kränzle
160 TS T
10 - 140 bar
160 bar
at 1400 U/min
11 l/min
max. 70 °C
2,5 m
yes
15 m
230 V ; 50 Hz ;
14 A
P1: 3,2 kW
P2: 2,4 kW
36 kg
350 x 330 x 900
89 dB
84 dB
approx. 25 Nm
26 Nm
Kränzle
195 TS T
10 - 180 bar
195 bar
at 1400 U/min
7,5 l/min
max. 70 °C
2,5 m
no
15 m
230 V ; 50 Hz ;
13,5 A
P1: 3,2 kW
P2: 2,4 kW
36 kg
350 x 330 x 900
89 dB
84 dB
approx.32 Nm
28 Nm
Instructions for use
The KRÄNZLE 160 TS T
and KRÄNZLE 195 TS T
have an electrical start-stop
control.
After connecting the water
and the HP hose, switch the
ON/OFF switch to ON. The
red light in the switch will
then illuminate.
The motor is started by
opening the gun, and
switched off by closing it.
The system remains ready
for use until the ON/OFF
switch is switched to OFF.
The red light in the switch
will then extinguish.
After switching the sys
tem off, press the trigger of
the gun to release the
pressure. You can now
unscrew the HP hose.
(Assumed lenght of lance: 0.9 m)
DescriptionDescription
DescriptionDescription
Description
- facades
- flagstones
- terraces
- vehicles of all types
- containers
- machines etc.
- removing of
old paint
