Kranzle K 160 TST - Lance with Trigger Gun; Unloader Valve - Safety Valve

4
WW
WW
W
ater and Cleaning Systemater and Cleaning System
ater and Cleaning Systemater and Cleaning System
ater and Cleaning System
Water can be connected at mains pressure to the high pressure pump or it can be
sucked directly from a storage tank. The water is then forced under pressure by
the high pressure pump to the lance. The high pressure jet is formed by the nozzle
at the end of the lance.
Environmental, refuse disposal and water
protection regulations must be observed !
Lance with trigger gun
The machine can only be operated when the safety trigger is squeezed.
The machine can only be operated when the safety trigger is squeezed. When the
lever is squeezed, the spray gun opens. The liquid is then pumped to the nozzle.
The spray pressure increases and quickly reaches the selected operating pressure.
When the trigger is released, the trigger gun closes and any further spraying of
liquid from the lance is stopped.
The increase in pressure when the trigger gun is closed causes the unloader valve-
safety valve to open. The motor is cut off by the pressure switch. When the trigger
gun is opened, the unloader valve - safety valve closes, the motor is started again
and the pump ressumes pressure spraying from the lance.
The trigger gun is a safety device. Repairs should only be per-
formed by qualified persons. Should replacement parts be
required, use only components authorized by the manu-
facturer.
Unloader valve - safety valveUnloader valve - safety valve
Unloader valve - safety valveUnloader valve - safety valve
Unloader valve - safety valve
The unloader valve - safety valve protects the machine from a build p of excess
pressure, and is designed not to permit an excess pressure to be selected for
operation. The limit nut on the handle is sealed with a spray coating
The operating pressure and spray rate can be steplessly adjusted by turning the
handle.
Replacements, repairs, new adjustments and sealing
should only be performed by qualified persons.
DescriptionDescription
DescriptionDescription
Description
