Technical data K1622 TS
Operating press. fully adjustable 10-110 bar / 150-1600 psi
Nozzle size 028
Permissible overpressure 120 bar / 1800 psi
Water output at 1.700 rpm 1,7 GPM
Water inlet temperature max. 140 °F
Suction height 1 m
Steel braided high-pressure hose 10 m
Connected load 115 V, 14 A, 60 Hz
Power input P 1 - 1,6 kW
Power output P 2 - 1,5 HP
Weight 23 kg
Dim. incl. handle in mm 300 x 330 x 800
Emmisions sound pressure level at the workplace* L
pa
69,2 dB (A)
Sound power* L
WA
81,7 dB (A)
Recoil at lance ca. 27 N
Vibration at lance** 0,99 m/s
2
measurement uncertainty lance** 0,50 m/s
2
Vibration at Schmutzkiller lance** 2,92 m/s
2
measurement uncertainty Schmutzkiller lance** 1,46 m/s
2
Permissible tolerance for figures ± 5 % acc. to VDMA uniform sheet 24411
* tested according to DIN EN ISO 3744 and DIN EN ISO 11203 (distance 1m)
** tested according to DIN EN ISO 5349-1
