Kraus KPF-1621 - Faucet Installation Methods

6
Installation Method 1
Faucet Installation Methods
The minimum distance between the
faucet hole and the wall should be 3.5”
Minimum distance 3.5”
Less than 3.5”
30˚
Minimum distance 3.5”
Less than 3.5”
30˚
Installation Method 2
If the distance between the faucet hole
and the wall is less than 3.5”, position the
faucet lever 30 degrees to 90 degrees off
of the wall to allow for full operation
