Kreg KMA4100 - Assembly; Attach Material Support Wings; Attach Sure-Cut Back Board

4
Assembly
Complete the steps in this section to assemble your Crosscut Station.
1
Attach the Material Support Wings
a. Attach the right and left material support wings (D)
to the cutting base (A) using four small screws (AA).
2
Attach the Sure-Cut™ Back Board
a. Attach the front blade guard actuator board (H) and Sure-Cut™ back board (E) in place using four large screws
(CC).
H
E
CC
AA
A
D
