FCU 500, FCU 505 · Edition 02.17 65
Fieldbus communication via Ethernet
Remaining times (FCU ➔ PLC)
This module/register transfers the remaining times of
various processes from the FCU to the PLC. The re-
maining time occupies 2 bytes.
Bit Byte n Byte n+1 Data type Format Value
0
1
2
3
4
5
6
7
Remaining times Word DEC
0–6554
(0 to 6554 s)
Remaining times of the valve proving system
(FCU ➔ PLC)
Only for FCU..C1.
The module/register in FCU..C0 contains no information.
This module/register transfers the remaining time of
the valve proving system from the FCU..C1 to the PLC.
The remaining time occupies 2 bytes.
The valve check runs parallel to other time-related pro-
cesses, e.g. pre-purge. To display the remaining time
of the valve proving system separately, it is transferred
separately.
Bit Byte n By te n+1 Data type Format Value
0
1
2
3
4
5
6
7
Remaining times of the
valve proving system
Word DEC
0–6554
(0 to 6554 s)
▼
