FCU 500, FCU 505 · Edition 02.17 77
Parameters
Name Parameter Value range Description Factory default settings
Function of terminal 51 69
0
1
2
3
4
5
6
Off
Feedback of position for maximum
capacity (IC 40/RBW)
AND with emergency stop (trm. 46)
AND with air min. (trm. 47)
AND with air flow monitoring (trm. 48)
AND with gas min. (trm. 49)
AND with gas max. (trm. 50)
0
Function of terminal 65 70
0
1
2
3
4
5
6
Off
Reduced DG test duration
AND with emergency stop (trm. 46)
AND with air min. (trm. 47)
AND with air flow monitoring (trm. 48)
AND with gas min. (trm. 49)
AND with gas max. (trm. 50)
0
Function of terminal 66 71
0
1
2
3
4
5
6
7
Off
FCU as zone control unit
External HT signal
AND with emergency stop (trm. 46)
AND with air min. (trm. 47)
AND with air flow monitoring (trm. 48)
AND with gas min. (trm. 49)
AND with gas max. (trm. 50)
0
Function of terminal 67 72
0
1
2
3
4
5
6
7
Off
BCU ready; if not, safety shut-down
BCU ready; if not, fault lock-out
AND with emergency stop (trm. 46)
AND with air min. (trm. 47)
AND with air flow monitoring (trm. 48)
AND with gas min. (trm. 49)
AND with gas max. (trm. 50)
2
Function of terminal 68 73
0
1
2
3
4
5
6
Off
Contactor feedback
AND with emergency stop (trm. 46)
AND with air min. (trm. 47)
AND with air flow monitoring (trm. 48)
AND with gas min. (trm. 49)
AND with gas max. (trm. 50)
0
▼
