Faults
DANGER
Electric shocks can be fatal! Before working on
possible live components, ensure the unit is discon-
nected from the power supply.
Fault-clearance must only be undertaken by author-
ized, trained personnel.
Faults may be cleared only using the measures
described below.
If the PFA does not respond even though all faults
have been remedied: remove the unit and return
it to the manufacturer for inspection.
? Faults
! Cause
Remedy
? The 7-segment display does not light up.
! Mains voltage is not applied.
Check the wiring, apply mains voltage (see type
label).
? The display blinks and indicates
P
or
? A bus fault is indicated on the automation
system.
! The PROFIBUS DP data traffic has suffered a
fault.
! Bus cable interrupted.
Check bus cable.
! Bus cable connections confused in the plug.
Check the wiring.
! A and B cables confused.
Check cables.
! Terminal resistors connected incorrectly.
Switch on the terminal resistors on the first and
last station in the segment and switch them off
for all other stations.
! Incorrect PROFIBUS address set.
Correct the address setting switch the unit off
and then on again to save the address.
! Bus cables too long.
Reduce cable length or baud rate see page
5 (Commissioning).
If the transfer rate is reduced, remember that
this will increase the signal running times to and
from the individual units.
! Poor shielding.
The shield must be connected to the shield clips
in the PROFIBUS DP plugs in full and over a wide
area.
! Poor equipotential bond.
The PROFIBUS DP shield should be connected
at all points to the same ground potential by
grounding the BGT. If necessary an equipotential
bond cable must be laid.
! If faults only occur sporadically in the PROFIBUS
DP system, and are mostly only indicated briey
in the bus master, the terminal resistors, shield-
ing, cable lengths/routes, equipotential bond
and the use of interference-suppressed ignition
electrode plugs (1 kΩ) in particular should be
checked.
Further notes on building PROFIBUS DP net-
works are set out in the instructions for the au-
tomation system or, for example, in the “Installa-
tion Guideline for PROFIBUS DP/FMS”, available
from the PUO (PROFIBUS User Organization).
? All the burners are constantly in operation,
regardless of data traffic.
! The PFA is set to manual mode.
Switch the PFA to “normal operation”.
? The display indicates
.
! Profibus module fault.
Remove the unit and return it to the manufacturer.
? The display indicates
30
,
31
,
34
,
80
,
89
,
94
,
95
,
96
,
97
,
98
or
99
.
! Internal faults.
Remove the unit and return it to the manufacturer.
