25
9. Technical Data
Three point linkage standard standard
Tandem axle standard standard
Number of arms 10 11
Number of double tines per arm 3 4
Working width mm 3500 3900
Swath rotor diameter mm 2900 3200
Height mm 2300 2400
Height in operating position mm 1600 1600
Length mm 2600 2800
Width in transport position mm 1800 2020
Width in operating positon mm 3600 4000
Power requipment approx. kW/HP 26/35 29/40
PTO shaft speed max. permitted drive speed
540 t/min 540 t/min
recommended operating drive speed 350–450 t/min 350–450 t/min
Equivalent continous sound pressure lev. below 70 db (A) below 70 db (A)
Acreage capacity approx. per hour 3,5 4,5
Tyres 16 x 6.50-8 16 x 6.50-8
Tyres pressure bar 1,5 1,5
Weight of machine kg 600 660
Swadro 395
Swadro 355Type
