Fan Powered Terminal Units IOM
6. Cap the ‘T’ taps.
7. Reset the thermostat to a normal setting.
NOTE: It is normal for the total airow to the room to
increase slightly in full cooling mode.
TABLE 8 – KQFS Series Fan Terminal Unit
UNIT SIZE INLET SIZE
PRIMARY AIR FLOW PCS MOTOR EC MOTOR
MAX MIN MOTOR HP MAX FAN MIN FAN MOTOR HP MAX FAN MIN FAN
2
6 515 90
1/10 530 50 N/A
8 530 160
3
6 515 90
1/4 1110 200 1/2 1050 250
8 920 160
10 1110 250
12 1110 360
4
8 920 160
1/4 1400 500 N/A10 1400 250
12 1400 360
5
10 1425 250
1/2 1850 800 N/A12 1850 360
14 1850 480
6
10 1425 250
3/4 2600 1200 1 2000 500
12 2060 360
14 2600 480
16 2600 630
7
10 1425 250
1 3000 1250 1 2500 600
12 2060 360
14 2800 480
16 3000 630
TABLE 8 – KQFS Series Fan Terminal Unit
