Fan Powered Terminal Units IOM
TABLE 9 – QFC Series Fan Terminal Unit
UNIT SIZE INLET SIZE
PRIMARY AIR FLOW PCS MOTOR ECM MOTOR
MAX MIN MOTOR HP MAX FAN MIN FAN MOTOR HP MAX FAN MIN FAN
2 6 515 90 1/10 560 100 N/A
3
6 515 90
1/4 990 300 1/2 1100 275
8 920 160
4
8 920 160
1/4 1440 550 N/A10 1430 250
12 1440 360
5
10 1430 250
1/2 2140 1100 N/A
12 2060 360
6
12 2060 360
3/4 2530 1200 1 2550 650
14 2530 480
7 16 3660 630 (2)3/4 3900 2100 (2)1 4550 1125
TABLE 10 – KLPS Series Fan Terminal Unit
UNIT SIZE INLET SIZE
PRIMARY AIR FLOW PCS MOTOR ECM MOTOR
MAX MIN MOTOR HP MAX FAN MIN FAN MOTOR HP MAX FAN MIN FAN
1
4 230 40
N/A 1/3 850 1255 350 62
6 515 90
2
6 515 90
N/A 1/3 925 140
8 860 160
3
8 920 160
1/4 1075 460 1/3 1125 170
10 1075 250
4
10 1425 250
(2)1/6 1650 805 (2)1/3 1900 285
8X14 1650 360
5
8 920 160
1/2 1970 840 1/3 1790 265
10 1425 250
12 1970 360
14 1970 480
TABLE 9 – QFC Series Fan Terminal Unit
TABLE 10 – KLPS Series Fan Terminal Unit
