KRUEGER KLPS - Page 35

35
Fan Powered Terminal Units IOM
Set
Point
CFM
MANUAL %
Display
(option 6)
REMOTE 0-10Vdc (0-20mA)
DC Signal (option 7)
REMOTE 2-10Vdc (4-20mA)
DC Signal (option 8)
775 100 10 (20.0) 10 (20.0)
768 99 9.9 (19.8) 9.9 (19.8)
760 98 9.8 (19.6) 9.8 (19.7)
752 97 9.7 (19.4) 9.8 (19.5)
744 96 9.6 (19.2) 9.7 (19.4)
737 95 9.5 (19.0) 9.6 (19.2)
729 94 9.4 (18.8) 9.5 (19.0)
721 93 9.3 (18.6) 9.4 (18.9)
713 92 9.2 (18.4) 9.4 (18.7)
706 91 9.1 (18.2) 9.3 (18.6)
698 90 9.0 (18.0) 9.2 (18.4)
690 89 8.9 (17.8) 9.1 (18.2)
682 88 8.8 (17.6) 9.0 (18.1)
675 87 8.7 (17.4) 9.0 (17.9)
667 86 8.6 (17.2) 8.9 (17.8)
659 85 8.5 (17.0) 8.8 (17.6)
651 84 8.4 (16.8) 8.7 (17.4)
644 83 8.3 (16.6) 8.6 (17.3)
636 82 8.2 (16.4) 8.6 (17.1)
628 81 8.1 (16.2) 8.5 (17.0)
620 80 8.0 (16.0) 8.4 (16.8)
613 79 7.9 (15.8) 8.3 (16.6)
605 78 7.8 (15.6) 8.2 (16.5)
597 77 7.7 (15.4) 8.2 (16.3)
589 76 7.6 (15.2) 8.1 (16.2)
582 75 7.5 (15.0) 8.0 (16.0)
574 74 7.4 (14.8) 7.9 (15.8)
566 73 7.3 (14.6) 7.8 (15.7)
558 72 7.2 (14.2) 7.8 (15.5)
551 71 7.1 (14.0) 7.7 (15.4)
543 70 7.0 (13.8) 7.6 (15.2)
535 69 6.9 (13.6) 7.5 (15.0)
527 68 6.8 (13.6) 7.4 (14.9)
520 67 6.7 (13.4) 7.4 (14.7)
512 66 6.6 (13.2) 7.3 (14.6)
504 65 6.5 (13.0) 7.2 (14.4)
496 64 6.4 (12.8) 7.1 (14.2)
489 63 6.3 (12.6) 7.0 (14.1)
481 62 6.2 (12.4) 7.0 (13.9)
473 61 6.1 (12.2) 6.9 (13.8)
465 60 6.0 (12.0) 6.8 (13.6)
458 59 5.9 (11.8) 6.7 (13.4)
450 58 5.8 (11.6) 6.6 (13.3)
442 57 5.7 (11.4) 6.6 (13.1)
434 56 5.6 (11.2) 6.5 (13.0)
427 55 5.5 (11.0) 6.4 (12.8)
419 54 5.4 (10.8) 6.3 (12.6)
411 53 5.3 (10.6) 6.2 (12.5)
403 52 5.2 (10.4) 6.2 (12.3)
396 51 5.1 (10.2) 6.1 (12.2)
Set
Point
CFM
MANUAL %
Display
(option 6)
REMOTE 0-10Vdc (0-20mA)
DC Signal (option 7)
REMOTE 2-10Vdc (4-20mA)
DC Signal (option 8)
388 50 5 (10.0) 6.0 (12.0)
380 49 4.9 (9.8) 5.9 (11.8)
372 48 4.8 (9.6) 5.8 (11.7)
365 47 4.7 (9.4) 5.8 (11.5)
357 46 4.6 (9.2) 5.7 (11.4)
349 45 4.5 (9.0) 5.6 (11.2)
341 44 4.4 (8.8) 5.5 (11.0)
334 43 4.3 (8.6) 5.4 (10.9)
326 42 4.2 (8.4) 5.4 (10.7)
318 41 4.1 (8.2) 5.3 (10.6)
310 40 4 (8.0) 5.2 (10.4)
303 39 3.9 (7.8) 5.1 (10.2)
295 38 3.8 (7.6) 5.0 (10.1)
287 37 3.7 (7.4) 5.0 (9.9)
279 36 3.6 (7.2) 4.9 (9.8)
272 35 3.5 (7.0) 4.8 (9.6)
264 34 3.4 (6.8) 4.7 (9.4)
256 33 3.3 (6.6) 4.6 (9.3)
248 32 3.2 (6.4) 4.6 (9.1)
241 31 3.1 (6.2) 4.5 (9.0)
233 30 3 (6.0) 4.4 (8.8)
225 29 2.9 (5.8) 4.2 (8.6)
217 28 2.8 (5.6) 4.2 (8.5)
210 27 2.7 (5.4) 4.1 (8.3)
202 26 2.6 (5.2) 4.0 (8.2)
194 25 2.5 (5.0) 3.9 (8.0)
186 24 2.4 (4.8) 3.8 (7.8)
179 23 2.3 (4.6) 3.8 (7.7)
171 22 2.2 (4.4) 3.6 (7.5)
163 21 2.1 (4.2) 3.7 (7.4)
155 20 2 (4.0) 3.6 (7.2)
148 19 1.9 (3.8) 3.5 (7.0)
140 18 1.8 (3.6) 3.4 (6.9)
132 17 1.7 (3.4) 3.4 (6.7)
124 16 1.6 (3.2) 3.3 (6.6)
117 15 1.5 (3.0) 3.2 (6.4)
109 14 1.4 (2.8) 3.1 (6.2)
101 13 1.3 (2.6) 3.0 (6.1)
93 12 1.2 (2.4) 3.0 (5.9)
86 11 1.1 (2.2) 2.9 (5.8)
78 10 1 (2.0) 2.8 (5.6)
70 9 0.9 (1.8) 2.7 (5.4)
62 8 0.8 (1.6) 2.6 (5.3)
55 7 0.7 (1.4) 2.6 (5.1)
47 6 0.6 (1.2) 2.5 (5.0)
39 5 0.5 (1.0) 2.4 (4.8)
31 4 0.4 (0.8) 2.3 (4.6)
24 3 0.3 (0.6) 2.2 (4.5)
16 2 0.2 (0.4) 2.2 (4.3)
8 1 0.1 (0.2) 2.1 (4.2)
CFM VALUES BELOW RECOMMENDED MINIMUM MAY AFFECT LIFE OF MOTOR.
TABLE 27 KLPS-D Size 1 ECM CALIBRATION
