Fan Powered Terminal Units IOM
Set
Point
CFM
MANUAL %
Display
(option 6)
REMOTE 0-10Vdc (0-20mA)
DC Signal (option 7)
REMOTE 2-10Vdc (4-20mA)
DC Signal (option 8)
875 100 10 (20.0) 10 (20.0)
867 99 9.9 (19.8) 9.9 (19.8)
858 98 9.8 (19.6) 9.8 (19.7)
849 97 9.7 (19.4) 9.8 (19.5)
840 96 9.6 (19.2) 9.7 (19.4)
832 95 9.5 (19.0) 9.6 (19.2)
823 94 9.4 (18.8) 9.5 (19.0)
814 93 9.3 (18.6) 9.4 (18.9)
805 92 9.2 (18.4) 9.4 (18.7)
797 91 9.1 (18.2) 9.3 (18.6)
788 90 9.0 (18.0) 9.2 (18.4)
779 89 8.9 (17.8) 9.1 (18.2)
770 88 8.8 (17.6) 9.0 (18.1)
762 87 8.7 (17.4) 9.0 (17.9)
753 86 8.6 (17.2) 8.9 (17.8)
744 85 8.5 (17.0) 8.8 (17.6)
735 84 8.4 (16.8) 8.7 (17.4)
727 83 8.3 (16.6) 8.6 (17.3)
718 82 8.2 (16.4) 8.6 (17.1)
709 81 8.1 (16.2) 8.5 (17.0)
700 80 8.0 (16.0) 8.4 (16.8)
692 79 7.9 (15.8) 8.3 (16.6)
683 78 7.8 (15.6) 8.2 (16.5)
674 77 7.7 (15.4) 8.2 (16.3)
665 76 7.6 (15.2) 8.1 (16.2)
657 75 7.5 (15.0) 8.0 (16.0)
648 74 7.4 (14.8) 7.9 (15.8)
639 73 7.3 (14.6) 7.8 (15.7)
630 72 7.2 (14.2) 7.8 (15.5)
622 71 7.1 (14.0) 7.7 (15.4)
613 70 7.0 (13.8) 7.6 (15.2)
604 69 6.9 (13.6) 7.5 (15.0)
595 68 6.8 (13.6) 7.4 (14.9)
587 67 6.7 (13.4) 7.4 (14.7)
578 66 6.6 (13.2) 7.3 (14.6)
569 65 6.5 (13.0) 7.2 (14.4)
560 64 6.4 (12.8) 7.1 (14.2)
552 63 6.3 (12.6) 7.0 (14.1)
543 62 6.2 (12.4) 7.0 (13.9)
534 61 6.1 (12.2) 6.9 (13.8)
525 60 6.0 (12.0) 6.8 (13.6)
517 59 5.9 (11.8) 6.7 (13.4)
508 58 5.8 (11.6) 6.6 (13.3)
499 57 5.7 (11.4) 6.6 (13.1)
490 56 5.6 (11.2) 6.5 (13.0)
482 55 5.5 (11.0) 6.4 (12.8)
473 54 5.4 (10.8) 6.3 (12.6)
464 53 5.3 (10.6) 6.2 (12.5)
455 52 5.2 (10.4) 6.2 (12.3)
447 51 5.1 (10.2) 6.1 (12.2)
Set
Point
CFM
MANUAL %
Display
(option 6)
REMOTE 0-10Vdc (0-20mA)
DC Signal (option 7)
REMOTE 2-10Vdc (4-20mA)
DC Signal (option 8)
438 50 5 (10.0) 6.0 (12.0)
429 49 4.9 (9.8) 5.9 (11.8)
420 48 4.8 (9.6) 5.8 (11.7)
412 47 4.7 (9.4) 5.8 (11.5)
403 46 4.6 (9.2) 5.7 (11.4)
394 45 4.5 (9.0) 5.6 (11.2)
385 44 4.4 (8.8) 5.5 (11.0)
377 43 4.3 (8.6) 5.4 (10.9)
368 42 4.2 (8.4) 5.4 (10.7)
359 41 4.1 (8.2) 5.3 (10.6)
350 40 4 (8.0) 5.2 (10.4)
342 39 3.9 (7.8) 5.1 (10.2)
333 38 3.8 (7.6) 5.0 (10.1)
324 37 3.7 (7.4) 5.0 (9.9)
315 36 3.6 (7.2) 4.9 (9.8)
307 35 3.5 (7.0) 4.8 (9.6)
298 34 3.4 (6.8) 4.7 (9.4)
289 33 3.3 (6.6) 4.6 (9.3)
280 32 3.2 (6.4) 4.6 (9.1)
272 31 3.1 (6.2) 4.5 (9.0)
263 30 3 (6.0) 4.4 (8.8)
254 29 2.9 (5.8) 4.2 (8.6)
245 28 2.8 (5.6) 4.2 (8.5)
237 27 2.7 (5.4) 4.1 (8.3)
228 26 2.6 (5.2) 4.0 (8.2)
219 25 2.5 (5.0) 3.9 (8.0)
210 24 2.4 (4.8) 3.8 (7.8)
202 23 2.3 (4.6) 3.8 (7.7)
193 22 2.2 (4.4) 3.6 (7.5)
184 21 2.1 (4.2) 3.7 (7.4)
175 20 2 (4.0) 3.6 (7.2)
167 19 1.9 (3.8) 3.5 (7.0)
158 18 1.8 (3.6) 3.4 (6.9)
149 17 1.7 (3.4) 3.4 (6.7)
140 16 1.6 (3.2) 3.3 (6.6)
132 15 1.5 (3.0) 3.2 (6.4)
123 14 1.4 (2.8) 3.1 (6.2)
114 13 1.3 (2.6) 3.0 (6.1)
105 12 1.2 (2.4) 3.0 (5.9)
97 11 1.1 (2.2) 2.9 (5.8)
88 10 1 (2.0) 2.8 (5.6)
79 9 0.9 (1.8) 2.7 (5.4)
70 8 0.8 (1.6) 2.6 (5.3)
62 7 0.7 (1.4) 2.6 (5.1)
53 6 0.6 (1.2) 2.5 (5.0)
44 5 0.5 (1.0) 2.4 (4.8)
35 4 0.4 (0.8) 2.3 (4.6)
27 3 0.3 (0.6) 2.2 (4.5)
18 2 0.2 (0.4) 2.2 (4.3)
9 1 0.1 (0.2) 2.1 (4.2)
CFM VALUES BELOW RECOMMENDED MINIMUM MAY AFFECT LIFE OF MOTOR.
TABLE 28 KLPS-D Size 2 ECM CALIBRATION
