Krups KP 5006 - Page 62

R E P A I R
Assemblyinformation
Th enewextractionheadisequippedwithaTconnectionandthehotwaterpressure
hose.
1. Cutoffnewcoldwaterpressurehosesfromsparesiliconetube.
2. Leadnewpressurehosesthroughrubber bus hingsandconnectthem.
3. Pressextractionheadontocenterpar ttillall4latchesengage.
4. Screwdo wnextractionheadt ightly.
5. RoutewirestomainPCBaccordin gtomachineversion.
Alwaysusenewclipsforpressurehoseassembly.
Wrong wire routing
can cause malfunc-
tions.
