INSTALLATION
CONNECTING THE INNER WIRE
Insert the Locking Cable End through the slotted hole.
Insert the housing into the slotted cable stop.
Mast
Locking Cable End
Slotted Cable Stop
Cable Housing
Locking Cable End
Slotted Hole
Mast
