Option 2: Using Recourse Ultralight cable system
Install the LEV-Ci ferrule on the cable housing. Route the Recourse inner wire
as shown. Tighten the locking cable end leaving 13mm spacing as shown.
Trim the excess inner wire to be flush with the locking cable end.
CABLE INSTALLATION
3mm
2mm
Ferrule
Cable
Cable Housing
Locking
Cable
End
13mm
