SADDLE INSTALLATION
CRUX-i
Using a 5mm Hex wrench, loosen the two head clamp bolts until
they are nearly free of the upper half of the saddle clamp. Set the
fore/aft and angle position of the saddle. Tighten the two head
clamp bolts to a maximum torque of 15 N-m.
ETEN-i
Using a 6mm Hex wrench, loosen the single head clamp bolt until
it is nearly free of the upper half of the saddle clamp. Set the
fore/aft and angle position of the saddle. Tighten the head clamp
bolt to a maximum torque of 22 N-m.
13-15 N-m
20-22 N-m
18
