KSB BPHA 384 - UMAG;UMAH 150 (Above 15 HP) Motor Construction

Submersible Motor Pumps (150 mm and above)
14
14.2 UMAG 150 / UMAH 150 (Above 15HP)
* Recommended spare parts
Part No. Description
59-12 Diaphragm
68-2 Cover plate
81-34 Finger presser disc
81-59 Stator with winding
81-6 Winding protection cover
81-60 Thrust insert
132.51 Intermediate part (Lower)
132.52 Intermediate part (Upper)
160 Cover
271* Sand guard
382.51 Bearing body (Lower)
382.52 Bearing body (Upper)
384 Thrust bearing plate
387 Thrust bearing segment
389 Counter thrust bearing ring
392 Bearing segment carrier
411.51* Gasket
411.52* Gasket
421* Oil seal
545.51 Bearing bush (Lower)
545.52 Bearing bush (Upper)
550 Disc
550.51 Washer (Machined)
550.52 Washer (Punched)
580 Cap
818 Rotor
828* Cable packing ring
829.51 Cable gland ring
829.52 Cable pressure washer
902.51 Stud
902.52 Stud
903.51 Allen head plug
904 Threaded pin
920.51 Nut (Cap)
920.52 Nut (Hex)
932* Circlip
940.51 Key
940.52 Key
