- 12 -
 Select and confirm system setting menu ,then see Fig23to Fig28
Fig.23：system setting Fig.24：system setting Fig.25：system setting
Fig.26：System setting Fig.27：System setting Fig.28：System setting
 Select and confirm parallel menu，then see Fig.29 to Fig.30
Fig.29：Parallel setting Fig.30：Parallel setting
 Setting battery see Fig.31～Fig.34
Fig.31：battery setting Fig.32：battery setting Fig.33：battery setting
Fig.34 Battery setting
Setting
System set
V-level 220V
F-level 50Hz
Setting
System Set
Auto Enable
F-Range 5%
Setting
System set
V-upper 15%
V-lower -45%
Setting
System set
V-Fine 0.0
SW Times 9

Setting
System set
Mode on-line
Power Enable
Setting
System set
Output Enable
Buzzer Disable
Setting
Parallel set
ID: 1
P-Amount
1 
Setting
Parallel Set
P-Redund 0
LBS
NO LBS
Setting
Battery set
EOD 1.70
Batt Num
20
Setting
Battery set
Batt-G 1
Batt-C
7
Setting
Battery set
Boost 2.30
Float
2.20
Setting
Battery set
Boost Enable
