- 29 -
Between Normal mode
and battery mode
0ms
0ms。
Switch time
Between inverter and
bypass
unlock：＜15ms (50Hz), ＜13.33ms (60Hz)
Display LCD+LED
Safety
Meeting IEC62040-1 GB4943。
Max input voltage
320Vac，1Hr
Conduction ：IEC 62040-2
Radiation ：IEC 62040-2
EMI
Harmonics ：IEC 62040-2
EMS IEC 62040-2
MTBF 100000Hr
MTTR 30min
Isolation resistance
> 2MΩ（500Vdc）
Isolation intension
2820Vdc， <3.5mA，1min
Surge Meeting IEC60664-1 1.2/50uS+8/20uS 6kV/3kA.
Protection IP20
Strike Meeting YD/T 1095
Package Meeting YD/T 1095
Traffic Meeting YD/T 1095
Parallel circumfluence
1＋1≤8%，N＋1≤3%
Parallel equal current
1＋1≤8%，N＋1≤10%
Dimension & weight
DIMENSION
Capacity KVA 6KVA/5.4KW 10KVA/9KW
Height mm 655
Width mm 250
Depth mm 590
Net weight kg
6KVA：70Kg（S）/30（H）
10KVA：80Kg（S）/40（H）
Color Blackness
