TABLE OF CONTENTS
4
12.9 Adjusting the spring preload of the
shock absorber ................................ 88
13 SERVICE WORK ON THE CHASSIS............... 89
13.1 Raising the vehicle with the center
stand .............................................. 89
13.2 Removing the vehicle from the
center stand .................................... 89
13.3 Removing the seat ........................... 89
13.4 Mounting the seat ............................ 90
13.5 Checking for chain dirt ..................... 90
13.6 Cleaning the chain ........................... 90
13.7 Checking the chain tension ............... 91
13.8 Adjusting the chain tension............... 92
13.9 Checking the chain, rear sprocket,
and engine sprocket ......................... 93
13.10 Checking/correcting the fluid level of
the hydraulic clutch ......................... 94
13.11 Checking steering head bearing
play ................................................ 95
13.12 Removing the bottom triple clamp
cover .............................................. 96
13.13 Installing the bottom triple clamp
cover .............................................. 96
13.14 Removing the windshield.................. 96
13.15 Installing the windshield................... 97
13.16 Removing storage compartment......... 97
13.17 Installing storage compartment ......... 98
13.18 Removing the top fuel tank fairing ..... 98
13.19 Installing the top fuel tank fairing...... 99
13.20 Removing the bottom fuel tank
fairing............................................. 99
13.21 Installing the bottom fuel tank
fairing........................................... 100
13.22 Removing the front side spoiler ....... 101
13.23 Installing the front side spoiler ........ 102
13.24 Removing the front side cover ...... 102
13.25 Installing the front side cover ...... 103
13.26 Removing the mask spoiler .......... 104
13.27 Installing the mask spoiler .......... 106
13.28 Removing the engine guard............. 108
13.29 Installing the engine guard ............. 108
13.30 Removing the oil plug cover ............ 109
13.31 Installing oil plug cover .................. 109
13.32 Removing front fender .................... 109
13.33 Installing front fender..................... 109
13.34 Cleaning the dust boots of the fork
legs ........................................... 110
13.35 Removing the crash bar .............. 110
13.36 Installing the crash bar ............... 111
14 BRAKE SYSTEM ....................................... 113
14.1 Anti-lock braking system (ABS) ....... 113
14.2 Checking the brake discs ................ 114
14.3 Checking the front brake fluid
level ............................................. 115
14.4 Adding front brake fluid .............. 116
14.5 Checking the front brake linings ...... 117
14.6 Checking the rear brake fluid
level ............................................. 117
14.7 Adding rear brake fluid ............... 118
14.8 Checking the rear brake linings ....... 119
15 WHEELS, TIRES ....................................... 121
15.1 Removing the front wheel ............ 121
15.2 Installing the front wheel ............ 122
15.3 Removing the rear wheel ............. 123
15.4 Installing the rear wheel .............. 124
15.5 Checking the rear hub damping
rubber pieces ............................. 126
15.6 Checking the tire condition ............. 127
15.7 Checking tire pressure .................... 128
15.8 Checking spoke tension .................. 128
15.9 Using tire repair spray .................... 129
16 ELECTRICAL SYSTEM ............................... 130
16.1 Low beam ..................................... 130
16.2 High beam .................................... 130
16.3 Daytime running light (DRL)............. 130
16.4 Cornering light............................... 131
16.5 Removing the 12 V battery .......... 131
16.6 Installing the 12-V battery ........... 132
16.7 Charging the 12-V battery ........... 133
16.8 Changing the RACE-ON key
battery .......................................... 135
16.9 Changing the main fuse.................. 136
16.10 Changing the fuses in the fuse
box............................................... 137
16.11 Checking the headlight setting ........ 138
16.12 Adjusting the headlight range.......... 139
16.13 Diagnostics connector .................... 139
16.14 Accessories circuit 1 and
accessories circuit 2 front............... 139
16.15 Accessories circuit 1 and
accessories circuit 2, rear ............... 140
17 COOLING SYSTEM .................................... 141
17.1 Checking the coolant level in the
compensating tank......................... 141
17.2 Correcting the coolant level in the
compensating tank......................... 141
18 TUNING THE ENGINE............................... 143
18.1 Ride Mode .................................... 143
18.2 Motorcycle traction control (MTC).... 143
18.3 Slip Adjuster (optional)................... 144
18.4 Throttle Response (optional) ........... 144
