KTM 1290 SUPER ADVENTURE R 2021 User Manual

TABLE OF CONTENTS
5
19 SERVICE WORK ON THE ENGINE .............. 145
19.1 Checking the engine oil level........... 145
19.2 Changing the engine oil and oil
filter, cleaning the oil screens ...... 145
19.3 Adding engine oil........................... 148
20 CLEANING, CARE ..................................... 150
20.1 Cleaning the motorcycle ................. 150
20.2 Checks and maintenance steps for
winter operation............................. 151
21 STORAGE................................................. 153
21.1 Storage ......................................... 153
21.2 Preparing for use after storage......... 153
22 TROUBLESHOOTING ................................ 154
23 TECHNICAL DATA..................................... 156
23.1 Engine.......................................... 156
23.2 Engine tightening torques ............... 157
23.3 Capacities ..................................... 159
23.3.1 Engine oil ................................. 159
23.3.2 Coolant..................................... 159
23.3.3 Fuel ......................................... 160
23.4 Chassis ......................................... 160
23.5 Electrical system............................ 161
23.6 Tires............................................. 161
23.7 Fork.............................................. 161
23.8 Shock absorber.............................. 162
23.9 Chassis tightening torques .............. 163
24 DECLARATIONS OF CONFORMITY ............. 167
24.1 Declarations of conformity .............. 167
24.2 Country-specific declarations of
conformity (KTM RACE ON system
1)................................................. 167
24.3 Country-specific declarations of
conformity (KTM RACE ON system
2)................................................. 168
24.4 Country-specific declarations of
conformity (CCU‑2) ........................ 168
25 OPEN SOURCE ......................................... 169
25.1 Information on open source
software ........................................ 169
26 SUBSTANCES .......................................... 170
27 AUXILIARY SUBSTANCES ......................... 172
28 STANDARDS ............................................ 173
29 INDEX OF SPECIAL TERMS ....................... 174
30 LIST OF ABBREVIATIONS.......................... 175
31 LIST OF SYMBOLS.................................... 176
31.1 Red symbols.................................. 176
31.2 Yellow and orange symbols.............. 176
31.3 Green and blue symbols.................. 176
INDEX ............................................................. 177

KTM 1290 SUPER ADVENTURE R 2021 Specifications

General

Engine Type	2-cylinder, 4-stroke, V 75°
Displacement	1301 cc
Transmission	6-speed
Fuel Tank Capacity	23 liters
Seat Height	880 mm
Dry Weight	221 kg
Rear Suspension	WP XPLOR PDS shock absorber
Front Tire	90/90-21
Rear Tire	150/70-18
Compression Ratio	13.1:1
Starter	Electric
Cooling System	Liquid cooled
Lubrication	Forced oil lubrication with 3 oil pumps
Traction Control	MTC (Motorcycle Traction Control), lean-angle sensitive
Power	160 hp
Torque	138 Nm
Front Suspension	WP XPLOR 48 mm, fully adjustable
Front Brake	Dual 320 mm discs, 4-piston calipers
Rear Brake	Brembo 2-piston caliper, 267 mm disc
ABS	Bosch 9.1MP (Cornering ABS)
Ground Clearance	250 mm
Fuel System	Keihin EFI
Frame	Chromium-Molybdenum steel trellis frame, powder coated
