TECHNICAL DATA 22
137
Riding sag 105 mm (4.13 in)
Fitted length 477 mm (18.78 in)
Shock absorber fluid ( p. 141) SAE 2.5
22.9 Chassis tightening torques
Screw, intake air temperature sen-
sor
EJOTDELTA PT
®
45x12-Z 0.7 Nm (0.52 lbf ft)
Screw, oil fill level sensor G 3/4 " 7 Nm (5.2 lbf ft)
Screw, oil pump holder on oil tank EJOTDELTA PT
®
45x12-Z 0.7 Nm (0.52 lbf ft)
Screw, pressure regulator EJOT PT
®
K60x25‑Z 2.3 Nm (1.7 lbf ft)
Screw, radiator hoses clip 2.4 Nm (1.77 lbf ft)
Screw, seat fixing EJOT EJOFORM PT
®
K60x23/18 2.5 Nm (1.84 lbf ft)
Screw, start button M3 0.4 Nm (0.3 lbf ft)
Screw, stop button M3 0.4 Nm (0.3 lbf ft)
Screw, fixed grip M4 5 Nm (3.7 lbf ft)
Loctite
®
243™
Screw, service hour counter M4 0.8 Nm (0.59 lbf ft)
Screw, throttle valve body cover M4 2.6 Nm (1.92 lbf ft)
Screw, throttle valve body hose
clamp
M4 2.8 Nm (2.07 lbf ft)
Spoke nipple, front wheel M4.5 6 Nm (4.4 lbf ft)
Spoke nipple, rear wheel M4.5 6 Nm (4.4 lbf ft)
Remaining nuts, chassis M5 5 Nm (3.7 lbf ft)
Remaining screws, chassis M5 5 Nm (3.7 lbf ft)
Screw, battery terminal M5 2.5 Nm (1.84 lbf ft)
Screw, shock absorber adjusting
ring
M5 5 Nm (3.7 lbf ft)
Screws on main silencer M5 7 Nm (5.2 lbf ft)
Nut, cable on starter motor M6 4 Nm (3 lbf ft)
Remaining nuts, chassis M6 10 Nm (7.4 lbf ft)
Remaining screws, chassis M6 10 Nm (7.4 lbf ft)
Screw, ball joint of push rod on
foot brake cylinder
M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, battery support bracket M6 6 Nm (4.4 lbf ft)
Screw, cable on starter relay M6 6 Nm (4.4 lbf ft)
Screw, chain guide on link fork at
the front
M6x45 10 Nm (7.4 lbf ft)
Screw, chain guide on link fork at
the rear
M6x19 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, chain sliding guard M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, front brake disc M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, fuel tank spoiler on radiator M6 6 Nm (4.4 lbf ft)
Screw, hand lever M6 5 Nm (3.7 lbf ft)
Screw, indicator lamp bracket M6 5 Nm (3.7 lbf ft)
Screw, oil pump M6 6 Nm (4.4 lbf ft)
