KTM 500 EXC US User Manual

23 TECHNICAL DATA 118
Weight of rider: 85… 95 kg (187… 209 lb.) 4.8 N/mm (27.4 lb/in)
Fork length 932 mm (36.69 in)
Air chamber length 110
+10
−20
mm (4.33
+0.39
−0.79
in)
Fork oil per fork leg 610 ml (20.62 fl. oz.) Fork oil (SAE 4) (48601166S1) ( p. 121)
23.7.2 EXC Six Days US
Fork part number 24.18.7P.69
Fork WP Performance Systems Up Side Down 4860 MXMA 4CS
Compression damping
Comfort 14 clicks
Standard 12 clicks
Sport 10 clicks
Rebound damping
Comfort 14 clicks
Standard 12 clicks
Sport 10 clicks
Spring length with preload spacer(s) 475 mm (18.7 in)
Spring rate
Weight of rider: 65… 75 kg (143… 165 lb.) 4.4 N/mm (25.1 lb/in)
Weight of rider: 75… 85 kg (165… 187 lb.) 4.6 N/mm (26.3 lb/in)
Weight of rider: 85… 95 kg (187… 209 lb.) 4.8 N/mm (27.4 lb/in)
Fork length 932 mm (36.69 in)
Oil capacity per fork leg 630 ml (21.3 fl. oz.) Fork oil (SAE 4) (48601166S1) ( p. 121)
23.8 Shock absorber
Shock absorber part number 12.18.7L.69
Shock absorber WP Performance Systems 5018 PDS DCC
Compression damping, low-speed
Comfort 25 clicks
Standard 20 clicks
Sport 15 clicks
Compression damping, high-speed
Comfort 2 turns
Standard 1.5 turns
Sport 1.25 turns
Rebound damping
Comfort 28 clicks
Standard 24 clicks
Sport 22 clicks
Spring preload
Comfort 9 mm (0.35 in)
Standard 9 mm (0.35 in)
Sport 9 mm (0.35 in)
Spring rate
Weight of rider: 65… 75 kg (143… 165 lb.) 69 N/mm (394 lb/in)
Weight of rider: 75… 85 kg (165… 187 lb.) 72 N/mm (411 lb/in)
Weight of rider: 85… 95 kg (187… 209 lb.) 76 N/mm (434 lb/in)
Spring length 250 mm (9.84 in)
Gas pressure 10 bar (145 psi)
Static sag 33… 35 mm (1.3… 1.38 in)
Riding sag 105… 115 mm (4.13… 4.53 in)

KTM 500 EXC US Specifications

General

Bore x Stroke	95 mm x 72 mm
Transmission	6-speed
Seat Height	960 mm
ABS	No
Ground Clearance	355 mm
Starter	Electric starter
Engine Type	1-cylinder, 4-stroke engine
Power	Not available
Torque	Not available
Rear Suspension	WP Xplor PDS
Front Brake	260 mm disc
Rear Brake	220 mm disc
Fuel System	Keihin EFI
