KTM 65 sx 2011 - Checking Play of Steering Head Bearing; Adjusting Play of Steering Head Bearing

MAINTENANCE WORK ON THE CHASSIS 32
B00395-10
– Tighten screws .
Guideline
Screw, bottom triple clamp M8 25 Nm
(18.4 lbf ft)
B00397-10
– Tighten screw .
Guideline
Nut, steering stem M20x1.5 10 Nm (7.4 lbf ft)
– Position the fuel tank breather.
B00396-10
– Mount and tighten screw .
Guideline
Screw, top triple clamp M8 25 Nm
(18.4 lbf ft)
B00398-10
– Mount and tighten screws .
Guideline
Screw, top triple clamp M8 25 Nm
(18.4 lbf ft)
B00399-10
– Position brake caliper, mount and tighten screws .
Guideline
Screw, brake caliper M8 20 Nm
(14.8 lbf ft)
Loctite
®
243™
– Position the brake line and clamp. Mount and tighten screws .
– Install the front fender. ( p. 35)
– Install the start number plate. ( p. 34)
– Check that the wiring harness, cables, and brake and clutch lines can move freely
and are routed correctly.
–
Install the front wheel. x ( p. 58)
– Check play of steering head bearing. ( p. 33)
