KTM 65 sx 2011 - Checking Front Brake Fluid Level; Adding Front Brake Fluid

MAINTENANCE WORK ON THE CHASSIS 47
700419-01
– Move the clutch fluid reservoir mounted on the handlebar to a horizontal position.
– Remove screws .
– Remove cover  with diaphragm .
300670-10
– Fill bleeding syringe  with the appropriate hydraulic fluid.
Bleed syringe (50329050000)
Hydraulic fluid (15) ( p. 82)
–
On the slave cylinder, remove the bleeder screw and mount bleeding syringe .
300671-10
– Inject the liquid into the system until it escapes from drill hole  of the master
cylinder without bubbles.
– To prevent overflow, drain fluid occasionally from the master cylinder reservoir.
– Remove the bleeding syringe. Mount and tighten screws bleeder screw.
– Correct the fluid level of the hydraulic clutch.
Guideline
Fluid level under top level of container 4 mm (0.16 in)
– Position the cover with the diaphragm. Mount and tighten the screws.
