BRAKES 57
–
Remove the rear brake linings. x ( p. 55)
100811-10
– Remove screws .
– Take off cover with washer and membrane .
– Press the brake piston back to its basic position and make sure that no brake fluid
overflows from the brake fluid reservoir.
–
Install the rear brake linings. x ( p. 56)
100812-10
– Add brake fluid to level .
Guideline
Dimension (brake fluid level below
top edge of container)
10 mm (0.39 in)
Brake fluid DOT 4 / DOT 5.1 ( p. 82)
– Position the membrane and the cover with the washer. Mount and tighten the
screws.
Info
Clean up overflowed or spilt brake fluid immediately with water.
