What to do if the engine turns but does not start on my KTM Motorcycle?
If your KTM Motorcycle engine turns but does not start, consider the following: * **Operating error**: Make sure you are following the correct start procedure. * **Blown fuse 3**: Replace the fuse. * **Disconnected fuel hose**: Connect the plug-in connection of the fuel line. * **Electronic fuel injection error**: Use the KTM diagnostics tool to read the fault memory.
What to do if the ABS warning lamp lights up on my KTM 690 Enduro R 2019 Motorcycle?
If the ABS warning lamp lights up on your KTM Motorcycle, there could be several reasons: * The ABS fuse may be blown, in which case you should replace it. * There might be a significant difference in wheel speeds between the front and rear wheels. If this is the case, stop the vehicle, switch off the ignition, and then restart it. * There could be a malfunction in the ABS, which requires reading the ABS fault memory using the KTM diagnostics tool.
Why doesn't the engine turn when I press the starter button on my KTM Motorcycle?
If your KTM Motorcycle engine does not turn when you press the starter button, consider the following potential causes and solutions: * **Operating error**: Ensure you are following the correct start procedure. * **Discharged 12V battery**: Charge the battery and check the open-circuit current. * **Blown fuse**: Check and change fuse 1, 2, or 3 if they are blown. * **Main fuse burned out**: Replace the main fuse. * **No ground connection**: Verify the ground connection is present and secure.
Why is my KTM 690 Enduro R 2019 Motorcycle engine overheating?
If your KTM Motorcycle engine overheats, it could be due to several reasons: * Too little coolant in the cooling system. Check for leaks and verify the coolant level. * Dirty radiator fins. Clean the radiator fins. * Foam formation in the cooling system. Drain the coolant and then refill/bleed the system. * Buckled or damaged radiator hose. Replace the radiator hose. * Faulty thermostat. Check the thermostat. * Blown fuse 4. Replace the fuse. * Defect in the radiator fan system. Check the radiator fan system.
What does it mean if the malfunction indicator lamp lights up on my KTM 690 Enduro R 2019?
If the malfunction indicator lamp lights up on your KTM Motorcycle, it indicates an error in the electronic fuel injection. You should read out the fault memory using the KTM diagnostics tool.
Why does my KTM 690 Enduro R 2019 engine die during the journey?
If your KTM Motorcycle engine dies during a journey, it could be due to: * Lack of fuel: Refuel your motorcycle. * Blown fuse 1, 2, or 3: Replace the affected fuse.
What causes high oil consumption in my KTM 690 Enduro R 2019 Motorcycle?
If your KTM Motorcycle has high oil consumption, check the following: * Engine vent hose: Ensure the hose isn't bent; straighten it or replace if needed. * Engine oil level: Check and correct if it's too high. * Engine oil viscosity: Change the oil and filter and clean the oil screens if the oil is too thin.
Why does the engine only turn if the clutch lever is drawn on my KTM 690 Enduro R 2019 Motorcycle?
If the engine of your KTM Motorcycle only turns when the clutch lever is drawn, it may be because: * The vehicle is in gear: Shift the transmission to the neutral position. * The vehicle is in gear and the side stand is folded out: Shift the transmission to the neutral position.
Why are the headlight and parking light not functioning on my KTM 690 Enduro R 2019 Motorcycle?
If the headlight and parking light are not functioning on your KTM Motorcycle, it is likely that Fuse 6 is blown. Replace the fuse.
Why are the turn signal, brake light, and horn not functioning on my KTM Motorcycle?
If the turn signal, brake light, and horn are not functioning on your KTM Motorcycle, it's likely that Fuse 5 is blown. Replace the fuse.
Defines the intended purpose and limitations of the vehicle.
Describes improper uses of the vehicle and potential dangers.
General instructions for safe operation of the product.
Details warranty coverage and conditions related to authorized workshops.
Advises on the correct use of fuel and auxiliary substances.
Highlights the importance of proper service for vehicle performance and longevity.
Illustrates and labels various parts of the vehicle from the front left.
Illustrates and labels various parts of the vehicle from the rear right.
Locates and explains the vehicle identification number.
Identifies the location of the vehicle's type label.
Specifies the location of the engine number on the vehicle.
Details the clutch lever's location and function.
Describes the hand brake lever and its operation.
Explains the location and function of the throttle grip.
Details the light switch operation and its possible states.
Explains the combination switch for drive modes and traction control.
Describes the ignition and steering lock positions and functions.
Provides guidance on initial preparation and checks before riding.
Details the recommended procedure for running in the engine.
Advises on safe practices for loading the vehicle with luggage.
Lists pre-ride checks and maintenance measures for roadworthiness.
Provides instructions and warnings for starting the motorcycle engine.
Covers gear shifting techniques and general riding advice.
Details the process for cleaning the dust boots of the fork legs.
Explains how to check for play in the steering head bearing.
Describes how to check the drive chain for dirt and soiling.
Provides instructions for checking the drive chain tension.
Guides on adjusting the clutch lever position for rider comfort.
Explains the ABS system, its function, and warnings.
Details how to check the thickness and condition of brake discs.
Provides instructions for checking the front brake fluid level.
Guides on checking the thickness and condition of front brake linings.
Details the procedure for removing the front wheel.
Provides instructions for installing the front wheel.
Guides on checking tire condition, including cuts and tread depth.
Explains how to check and set tire pressure for various conditions.
Details the process for safely removing the 12-V battery.
Provides instructions and warnings for charging the 12-V battery.
Guides on locating and replacing the main fuse.
Details the procedure for replacing the ABS fuses.
Provides instructions and warnings for checking coolant level.
Details the process for draining the coolant from the system.
Guides on refilling and bleeding the cooling system.
Explains how to select between ROAD and OFFROAD drive modes.
Details how to activate and deactivate the traction control system.
Guides on checking the shift lever position relative to the rider's boot.
Provides instructions for checking the engine oil level.
Details the procedure for changing engine oil and filter.
Guides on how to add engine oil to the correct level.
Lists possible causes and actions for engine not starting.
Identifies causes and solutions for engine overheating issues.
Explains issues when the malfunction indicator lamp is illuminated.
General| Engine | Single cylinder, 4-stroke |
|---|---|
| Displacement | 693 cc |
| Bore x Stroke | 105 mm x 80 mm |
| Compression Ratio | 12.7:1 |
| Transmission | 6-speed |
| Seat Height | 910 mm |
| Fuel Capacity | 13.5 l |
| Starter | Electric starter |
| Lubrication | Forced oil lubrication with 2 oil pumps |
| Subframe | Aluminum |
| Suspension Travel Front | 250 mm |
| Suspension Travel Rear | 250 mm |
| Wheels | Spoked wheels with aluminum rims |
| Front Tire | 90/90-21" |
| Rear Tire | 140/80-18" |
| Steering Head Angle | 63.5° |
| Power | 74 hp |
| Fuel System | Electronic Fuel Injection |
| Final Drive | X-Ring chain |
| Front Suspension | WP XPLOR USD, 48 mm |
| Rear Suspension | WP XPLOR PDS |
| Front Brake | Disc brake, 300 mm |
| Rear Brake | Disc brake, 240 mm |
| Dry Weight | 146 kg |
| Cooling | Liquid |
| Clutch | APTC slipper clutch, hydraulically actuated |
| Frame | Chrome-molybdenum steel trellis frame, powder coated |
| Handlebar | Aluminum, tapered Ø 28/22 mm |
| Chain | 5/8 x 1/4 |
| Ignition | Electronic ignition with digital adjustment |
