6 CONTROLS
20
6.11 Grab handle
V01225-10
The grab handle
1
is used for maneuvering the motorcycle.
If you carry a passenger, the passenger can hold onto the grab
handles during the trip.
6.12 Passenger foot pegs
V01199-01
The passenger foot pegs can be folded up and down.
Possible states
• Passenger foot pegs folded up – For operation without a pas-
senger.
• Passenger foot pegs folded down – For operation with a pas-
senger.
6.13 Shift lever
V01271-11
The shift lever
1
is mounted on the left side of the engine.
V01271-10
The gear positions can be seen in the photograph.
The neutral or idle position is between the first and second gears.
