COMBINATION INSTRUMENT 7
25
7.6 Display
F02747-10
Info
The figure shows the start screen of the combination instrument. If the menu is opened, the speed is still
displayed.
1
Gear display
2
Heated grip (optional) ( p. 26)
3
Cruise control indicator (optional) ( p. 27)
4
Bluetooth
®
(optional)
5
Ride Mode ( p. 107)
6
Unit of speedometer
7
Fuel level display ( p. 27)
8
Coolant temperature indicator ( p. 27)
9
Fuel range display
bk
Speed
bl
Trip odometer ( p. 28)
bm
Ambient temperature
bn
Time ( p. 28)
bo
ABS display ( p. 28)
bp
Tachometer
bp
Shift warning light ( p. 28)
The shift warning light is integrated in the tachometer display.
