KTM 950 SUPERMOTO R Repair Manual

7-16
1
7
10
C_BF/1
6
25
brown 0.5
3
C_BA/1
brown 0.5
red-green 0.5
blue-white 0.5
pink 0.5
5 A
fuse
orange 0.5
yellow-brown 0.5
grey 0.5
violet-white 0.5
brown-white 0.5
black-brown 0.5
yellow-white 0.5
yellow-blue 0.5
rear
page 7/9
C
front
black-orange 0.5
octane selector
C_AS1/2
C_AB/9
C_AR/3
neutral switch (N) / 2nd gear / 3th gear
ignition coil
1
C_AM2/3
3
1
black 0.5
yellow 0.5
blue 0.5
orange 1
orange 0.5
20
brown 0.5
brown 0.5
black-blue 0.5
blue-grey 0.5
ignition switch
2nd 3th N
2
2
19
battery
31
31
2
2
C_BB/9
C_AL1/2
2
orange 1
C_AR1/2
3
pick up
C_AT/2
8
fuel pump relay
1
1
7
31
EPC 2
30
2
2
12
2
13
16
start/stop switch
26
4
EPC 1
1
1
30
C_AS/2
orange 0.5
1
4
C_AW1/2 C_AW/2
C_AT/2
fuel pump
orange 1
11
M
1
1
1
C_AO/26
U
C
E
18
2
30
1 2
page 2/9
B
throttle position sensor
C_AM/3
10 A
fuse
yellow-black 1
C_AF1/4
1
6
5
4
2
7
8
9
bk
3
Ignition system, ECU 950 Adventure
NOTE: this is a digital battery ignition system with the current supplied by the battery.
Battery voltage from the battery
1 flows to the ECU (control unit) 4 through the switched on ignition lock 2 and the switched
on emergency OFF switch
3.
The pulse generator
5 reports the crankshaft position to the ECU 4. The ECU uses this signal to calculate the ignition point for
each cylinder.
Battery voltage is supplied to both ignition coils
6 via the emergency OFF switch, the ground is switched by the ECU.
The coil on the fuel pump relay
7 obtains battery voltage from the ECU. After the ignition is switched on, the fuel pump relay
switches on for a few seconds and switches off again. If you start with the engine running, the fuel pump relay will stay on.
The fuel pump
8 obtains battery voltage from the battery through the switched on ignition lock 2 , via the fuse and the contact
on the fuel pump relay.
The throttle potentiometer (TPS)
9 reports the position of the carburetor throttle valves to the ECU via the yellow cable (on
connector AM or AR). The TPS is supplied with 5 volts of supply voltage (blue cable on connector AM or AR) by the ECU. The
black cable (on connector AM or AR) supplies the ground.
NOTE: See page 8-11 for the adjustment of the TPS.
The ECU receives a ground signal via the connected octane selector
bk (connector BA and BF) and uses the stored ignition curve
for fuel with a minimum octane number of 95 (ROZ 95). If the octane selector is disconnected (connectors BA and BF pulled
apart) the engine can be operated with fuel with a minimum quality of ROZ 80.
