KTM 990 Super Duke 2008 User Manual

OPERATION INSTRUMENTS »
11
3
2
1
TRIP 1 [1]
The trip meter 1 is always active and counts up to 999.9. It is used to measure the length
of the trip or the distance between 2 refueling stops.
TO RESET TRIP 1
To reset the trip meter 1 to zero, switch on the ignition, select the TRIP 1 display mode and
press the SET button more than 2 seconds.
Press the MODE button to go to the next display mode.
TRIP 2 [2]
The trip meter 2 is always active and counts up to 999.9. It is used just like TRIP 1.
TO RESET TRIP 2
To reset the trip meter 2 to zero, switch on the ignition, select the TRIP 2 display mode and
press the SET button more than 2 seconds.
Press the MODE button to go to the next display mode.
TRIP F [3]
When the fuel level reaches the reserve mark, the display will automatically switch to TRIP
F and begin to count (no matter which display mode was active before). At the same time,
the fuel warning lamp will light up. You will still have enough reserve fuel for at least 30
kilometers.
After refueling, it will take approx. 3 minutes for the fuel lamp to go out, TRIP F to auto-
matically reset to 0 and to return to the previous display mode.
NOTE:
Press the SET button for 2 seconds to switch off the fuel warning lamp.

KTM 990 Super Duke 2008 Specifications

General

Displacement	999 cc
Bore x Stroke	101 mm x 62.4 mm
Compression Ratio	11.5:1
Fuel System	Electronic Fuel Injection
Transmission	6-speed
Front Suspension	WP USD 48 mm
Rear Suspension	WP monoshock
Front Brakes	2 x 320 mm discs, 4-piston calipers
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Dry Weight	186 kg
Cooling System	Liquid-cooled
Ignition	Electronic
Final Drive	Chain
Engine Type	V-twin, 4-stroke
Max Power	120 hp @ 9, 000 rpm
Max Torque	100 Nm @ 7, 000 rpm
Rear Brakes	240 mm disc
Frame	Chromium-Molybdenum steel trellis
