4 TECHNICAL DATA 14

4.1 Chassis tightening torques

Screw air intake temperature sensor EJOT DELTA PT

45x12‑Z 2 Nm (1.5 lbf ft) –

Screw, air filter box cover EJOT PT

K60x20-Z 3 Nm (2.2 lbf ft) –

Screw, pressure regulator EJOT PT

K60x25‑Z 3 Nm (2.2 lbf ft) –

Screw, handle bar fixed grip, left M4 5 Nm (3.7 lbf ft) Loctite

243™

Spoke nipple, front wheel M4.5 6 Nm (4.4 lbf ft) –

Spoke nipple, rear wheel M4.5 6 Nm (4.4 lbf ft) –

Screw, battery terminal M5 2.5 Nm (1.84 lbf ft) –

Screw, frame protector M5 3 Nm (2.2 lbf ft) –

Screw, shock absorber adjusting ring M5 5 Nm (3.7 lbf ft) –

Remaining nuts, chassis M6 10 Nm (7.4 lbf ft) –

Remaining screws, chassis M6 10 Nm (7.4 lbf ft) –

Screw, ball joint of push rod on foot

brake cylinder

M6 10 Nm (7.4 lbf ft) Loctite

243™

Screw, chain sliding guard M6 6 Nm (4.4 lbf ft) Loctite

243™

Screw, electric starter cable connec-

tion

M6 4 Nm (3 lbf ft) –

Screw, front brake disc M6 14 Nm (10.3 lbf ft) Loctite

243™

Screw, rear brake disc M6 14 Nm (10.3 lbf ft) Loctite

243™

Screw, throttle grip M6 5 Nm (3.7 lbf ft) –

Fuel connection on fuel tank M8 10 Nm (7.4 lbf ft) –

Nut, foot brake lever stop M8 20 Nm (14.8 lbf ft) –

Nut, rear sprocket screw M8 35 Nm (25.8 lbf ft) Loctite

2701™

Nut, rim lock M8 12 Nm (8.9 lbf ft) –

Remaining nuts, chassis M8 25 Nm (18.4 lbf ft) –

Remaining screws, chassis M8 25 Nm (18.4 lbf ft) –

Screw side stand attachment

(XC‑F US)

M8 35 Nm (25.8 lbf ft) Loctite

2701™

Screw, bottom triple clamp M8 12 Nm (8.9 lbf ft) –

Screw, chain sliding piece M8 15 Nm (11.1 lbf ft) –

Screw, engine brace M8 25 Nm (18.4 lbf ft) Loctite

2701™

Screw, fork stub M8 15 Nm (11.1 lbf ft) –

Screw, front brake caliper M8 25 Nm (18.4 lbf ft) Loctite

243™

Screw, handlebar clamp M8 20 Nm (14.8 lbf ft) –

Screw, subframe M8 35 Nm (25.8 lbf ft) Loctite

2701™

Screw, top steering stem M8 20 Nm (14.8 lbf ft) Loctite

243™

Screw, top triple clamp M8 17 Nm (12.5 lbf ft) –

Engine carrying screw M10 60 Nm (44.3 lbf ft) –

Remaining nuts, chassis M10 45 Nm (33.2 lbf ft) –

Remaining screws, chassis M10 45 Nm (33.2 lbf ft) –

Screw, bottom shock absorber M10 60 Nm (44.3 lbf ft) Loctite

2701™

Screw, handlebar support M10 40 Nm (29.5 lbf ft) Loctite

243™

Screw, top shock absorber M10 60 Nm (44.3 lbf ft) Loctite

2701™

Nut, fuel pump M12 15 Nm (11.1 lbf ft) –

Nut, frame to linkage lever M14x1.5 80 Nm (59 lbf ft) –

Nut, linkage lever on swingarm M14x1.5 80 Nm (59 lbf ft) –

Nut, linkage lever to angle lever M14x1.5 80 Nm (59 lbf ft) –

Nut, swingarm pivot M16x1.5 100 Nm (73.8 lbf ft) –

Screw, front wheel spindle M20x1.5 35 Nm (25.8 lbf ft) –

Screw, top steering head M20x1.5 12 Nm (8.9 lbf ft) –

Screw-in nozzles, cooling system M20x1.5 12 Nm (8.9 lbf ft) Loctite

243™

Nut, rear wheel spindle M25x1.5 80 Nm (59 lbf ft) –
